HX-Z1R
3-22
Item
Parts number Parts name Ar
ea
Remarks
A
C 101 NCS21HJ-821X C CAPACITOR
C 102 NCS21HJ-221X C CAPACITOR
C 103 QEKJ0JM-227Z E CAPACITOR 220MF 20% 6.3V
C 104 NCB21HK-333X C CAPACITOR
C 105 NCB21HK-222X C CAPACITOR
C 106 QEKJ1CM-106Z E CAPACITOR 10MF 20% 16V
C 107 NCS21HJ-561X C CAPACITOR
C 108 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 109 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 110 NCB21HK-682X C CAPACITOR
C 111 NCB21HK-152X C CAPACITOR
C 113 NCB21HK-393X C CAPACITOR
C 121 NCS21HJ-331X C CAPACITOR
C 201 NCS21HJ-821X C CAPACITOR
C 202 NCS21HJ-221X C CAPACITOR
C 203 QEKJ0JM-227Z E CAPACITOR 220MF 20% 6.3V
C 204 NCB21HK-333X C CAPACITOR
C 205 NCB21HK-222X C CAPACITOR
C 206 QEKJ1CM-106Z E CAPACITOR 10MF 20% 16V
C 207 NCS21HJ-561X C CAPACITOR
C 208 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 209 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 210 NCB21HK-682X C CAPACITOR
C 211 NCB21HK-152X C CAPACITOR
C 213 NCB21HK-393X C CAPACITOR
C 221 NCS21HJ-331X C CAPACITOR
C 301 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V
C 302 NCB21HK-393X C CAPACITOR
C 303 QEKJ0JM-227Z E CAPACITOR 220MF 20% 6.3V
C 304 QEKJ1CM-226Z E CAPACITOR 22MF 20% 16V
C 305 QEKJ1CM-226Z E CAPACITOR 22MF 20% 16V
C 306 QEKJ1CM-226Z E CAPACITOR 22MF 20% 16V
C 307 NCB21HK-103X C CAPACITOR
C 308 NCB21HK-152X C CAPACITOR
C 310 NCB21HK-223X C CAPACITOR
C 313 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V
C 314 QCZ0202-155Z ML C CAPACITOR 1.5MF
C 316 QFG32AJ-223Z PP CAPACITOR .022MF 5% 100V
C 319 QFLM1HJ-472Z M CAPACITOR 4700PF 5% 50V
C 331 QEKJ1CM-476Z E CAPACITOR 47MF 20% 16V
C 371 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 374 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V
C 376 NCB21HK-103X C CAPACITOR
CN 31 QGF1205F1-06 CONNECTOR PRI/HEAD
CN 32 QGB2011M1-10 B TO B CONNECTO PRI/MECHA
CN 33 QGF1205F1-09 CONNECTOR PRI/MICON
CN 34 QGF1201F3-10 CONNECTOR PRI/AMP
D 375 MA3051/M/-X Z DIODE
FW 31 QUM024-06A2Z3 PARA RIBON WIRE
IC 31 BA3126N IC HEAD SW
IC 32 AN7317 IC PB&REC
IC 33 BU4094BCF-X IC
L 301 QQR1292-001 BIAS COIL
L 303 QQL244K-100Z INDUCTOR
Q
302 KTC3203/Y/-T TRANSISTOR OSC
Q
305 KTC3203/Y/-T TRANSISTOR
A
SW
Q
321 UN2213-X TRANSISTOR BUFFER
Q
371 KTA1271/OY/-T TRANSISTOR MOTER+B
Q
372 UN2212-X TRANSISTOR
Q
375 2SB562/C/-T TRANSISTOR SOLENOID DRIVE
Q
376 2SD601A/QR/-X TRANSISTOR
R 101 NRSA63J-220X MG RESISTOR
R 102 NRSA63J-182X MG RESISTOR
R 103 NRSA63J-242X MG RESISTOR
R 104 NRSA63J-122X MG RESISTOR
R 105 NRSA63J-104X MG RESISTOR
R 106 NRSA63J-332X MG RESISTOR
R 107 NRSA63J-123X MG RESISTOR
R 108 NRSA63J-562X MG RESISTOR
R 109 NRSA63J-102X MG RESISTOR
R 110 NRSA63J-272X MG RESISTOR
R 111 NRSA63J-363X MG RESISTOR
R 112 NRSA63J-222X MG RESISTOR
R 116 NRSA63J-102X MG RESISTOR
R 121 NRSA63J-153X MG RESISTOR
R 122 NRSA63J-102X MG RESISTOR
R 201 NRSA63J-220X MG RESISTOR
R 202 NRSA63J-182X MG RESISTOR
R 203 NRSA63J-242X MG RESISTOR
R 204 NRSA63J-122X MG RESISTOR
R 205 NRSA63J-104X MG RESISTOR
R 206 NRSA63J-332X MG RESISTOR
R 207 NRSA63J-123X MG RESISTOR
R 208 NRSA63J-562X MG RESISTOR
R 209 NRSA63J-102X MG RESISTOR
R 210 NRSA63J-272X MG RESISTOR
R 211 NRSA63J-363X MG RESISTOR
R 212 NRSA63J-222X MG RESISTOR
R 216 NRSA63J-102X MG RESISTOR
R 221 NRSA63J-153X MG RESISTOR
R 222 NRSA63J-102X MG RESISTOR
R 301 NRS181J-221X MG RESISTOR
R 303 NRSA63J-393X MG RESISTOR
R 304 NRS181J-101X MG RESISTOR
R 310 QRJ146J-4R7X UNF C RESISTOR 4.7 5% 1/4W
R 313 NRSA63J-2R2X MG RESISTOR
R 314 NRSA63J-153X MG RESISTOR
R 315 NRSA63J-101X MG RESISTOR
R 327 NRSA63J-474X MG RESISTOR
R 335 NRSA63J-152X MG RESISTOR
R 336 NRSA63J-472X MG RESISTOR
R 337 NRSA63J-332X MG RESISTOR
R 338 NRSA63J-392X MG RESISTOR
R 339 NRSA63J-222X MG RESISTOR
R 340 NRS181J-391X MG RESISTOR
R 341 NRSA63J-123X MG RESISTOR
R 342 NRSA63J-203X MG RESISTOR
R 343 NRSA63J-183X MG RESISTOR
R 353 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 371 NRSA63J-123X MG RESISTOR
R 372 NRSA63J-102X MG RESISTOR
R 375 NRSA02J-151X MG RESISTOR 1/8W
R 376 NRSA63J-472X MG RESISTOR
VR 31 QVP0008-203Z SEMI V RESISTOR BIAS ADJ
VR 37 QVP0008-103Z SEMI V RESISTOR TAPE SPEED ADJ
Item
Parts number Parts name Ar
ea
Electrical parts list (Cassette switch board)
Remarks
Block No. 08
A
CN 1 QGB2011L1-10 B TO B CONNECTO
D 1 1T3-T2 SI DIODE
IC 1 SG-105F3-BB,C PHOTO SENSER
P 1 QNZ0104-001 POST PIN
SW 1 QSW0832-001 LEAF SWITCH R.REC
SW 2 QSW0832-001 LEAF SWITCH TAPE
SW 5 QSW0832-001 LEAF SWITCH F.REC
SW 6 QSW0859-001 LEVER SWITCH
Electrical parts list (Head amplifier board)
Block No. 07
Item
Parts number Parts name Ar
ea
Remarks
A
