JVC In-Dash DVD Player KD-LX50R Service Manual

Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M1MM
55 WDM214540 WASHER 2 FOR CLUTCH ASS'
56 QYSPSPU1725M SCREW 4 LO.UNIT A+DIS.P
57 LV30981-004A *CLUTCH ASS'Y 1
58 LV10317-006A BUTTON PANEL 1
59 LV10318-001A BUTTON BASE 1
60 LV20615-002A PRESET BUTTON 1 1
61 LV20616-002A PRESET BUTTON 2 1
62 LV31613-001A FUNCTION BUTTON 1
63 LV41825-001A PLATE SPRING 1
64 VKZ4777-004 MINI SCREW 6
65 WJT0030-001A E-CARD WIRE 1
66 LV20617-004A DISPLAY PANEL 1
67 LV32035-001A D.P. PLATE 1
68 LV31614-001A FINDER 1
69 LV41469-001A UP DOWN B.ASS'Y 1
70 VYSH1R5-007 SPACER 2
71 LV41471-001A + - BUTTON ASSY 1
73 LV41505-001A REMOTE LENS 1
74 VKZ4777-001 MINI SCREW 4 D.PANEL+SW.PWB
75 WJT0031-001A E-CARD WIRE 1
76 LV31734-001A NAME PLATE 1
77 LV41143-001A SHEET 2
79 GE40101-001A PIN CAP 8
80 LV30943-201A REAR BRACKET 1
81 LV30946-005A REAR HEAT SINK 1
82 LV40790-001A PIN CORD BRKT 1
83 QYSDST2604Z SCREW 3
84 LV41200-003A SPESIAL SCREW 2
85 QYSDST2606Z SCREW 2
87 QYSDST2604Z SCREW 2
90 QNZ0392-001 RUBBER CONNECTO 2
91 LV41450-001A LCD FILTER 1
92 LV31601-001A LCD CASE 1
93 LV31600-001A LIGHTING CASE 1
94 LV41447-001A LIGHTING LENS
(
L 1
95 LV41448-001A LIGHTING LENS
(
R 1
96 QAM0178-001 PIN CORD ASS'Y 1
97 QAM0179-001 CAR CABLE 1
99 LV40848-007A SPACER
(
P
)
2
103 VMA4652-001SS EARTH PLATE 1
104 LV41863-001A POWER IC BRACKE 1
105 LV40792-001A REG.IC BRACKET 1
106 QMFZ039-150-T FUSE 1
107 QAM0105-002 CAR CABLE 1
108 QAM0237-001 CAR CABLE 1
109 FSYH4036-035 SHEET 1
110 LV32029-002A FRONT SHEET 1
111 SPACER(F)
112 LV40848-009A 2
LCD 1 QLD0110-001 LCD MODULE 1
SPACER(p)
LV40846-005A
3
(General assembly)
