JVC KD-ADV7380J - Page 15

(No.MA312)1-15
3.1.6 Removing the REAR COVER
(See Fig.8, 9)
(1) Remove the VOLUME KNOB.
(2) Remove the one screw G attaching the REAR COVER.
(See Fig.8)
(3) Remove the four screws H attaching the REAR COVER.
(See Fig.9)
(4) Disengage nine hooks c engaged REAR COVER. (See
Fig.9)
Fig.8
Fig.9
G
HH
HH
hook
c
hook
c
hook
c
hook
c
