(No.MA312)1-3
Design and specifications are subject to change without notice.
KD-DV7302/KD-DV7301
WAV Quantization Bit Rate 16 bit
Sampling Frequency 44.1 kHz
USB SECTION
USB Standard USB 1.1/USB 2.0
Data Transfer Rate Full Speed Max. 12 Mbps
Low Speed Max. 1.5 Mbps
Compatible Device Mass storage class
Compatible File System FAT 12/16/32
Playable Audio/Video Format DivX/MPEG Video/MP3/WMA/AAC/WAV
Max. Current 500 mA
GENERAL
Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground
Allowable Operating Temperature 0
°
C to +40
°
C (32
°
F to 104
°
F)
Dimensions (W
×
H
×
D) Installation Size (approx.) 182 mm
×
52 mm
×
158 mm (7-3/16"
×
2-1/16"
×
6-1/4")
Panel Size (approx.) 188 mm
×
58 mm
×
12 mm (7-7/16"
×
2-5/16"
×
1/2")
Mass (approx.) 1.6 kg (3.6 lbs) (excluding accessories)
AUDIO AMPLIFIER SECTION
Maximum Power Output Front/Rear 50 W per channel
Continuous Power Output (RMS) Front/Rear 19 W per channel into 4
Ω
, 40 Hz to 20 000 Hz at no more than 0.8% total har-
monic distortion
Load Impedance 4
Ω
(4
Ω
to 8
Ω
allowance)
Equalizer Control Range Frequencies 60 Hz, 150 Hz, 400 Hz, 1 kHz, 2.5 kHz, 6.3 kHz, 15 kHz
Level ±10 dB
Signal to Noise Ratio 70 dB
Audio Output Level Digital (DIGITAL OUT: Optical) Signal wave length: 660 nm
Output level: -21 dBm to -15 dBm
Line-Out Level/Impedance 2.5 V/20 k
Ω
load (full scale)
Output Impedance 1 k
Ω
Subwoofer-out Level/Impedance 2.5 V/20 k
Ω
load (full scale)
Color system PAL
Video Output (composite) 1 Vp-p/75
Ω
Other Terminal CD changer, steering wheel remote input, LINE IN, 2nd AUDIO OUT
TUNER SECTION
Frequency Range FM 87.5 MHz to 108.0 MHz
AM (MW) 522 kHz to 1 620 kHz
(LW) 144 kHz to 279 kHz
FM Tuner Usable Sensitivity 11.3 dBf (1.0
µ
V/75
Ω
)
50 dB Quieting Sensitivity 16.3 dBf (1.8
µ
V/75
Ω
)
Alternate Channel Selectivity (400 kHz) 65 dB
Frequency Response 40 Hz to 15 000 Hz
Stereo Separation 30 dB
MW Tuner Sensitivity/Selectivity 20
µ
V/35 dB
LW Tuner Sensitivity 50
µ
V
DVD/CD PLAYER SECTION
Signal Detection System Non-contact optical pickup (semiconductor laser)
Number of Channels 2 channels (stereo)
