3-3
General assembly
Block No. [M][1][M][M]
Symbol No.
Part No. Part Name Description Local
1 GE30975-001A FRONT BKT ASSY
2 FSYH4036-100 SHEET
3 GE40218-012A SHEET (x2)
4 GE30972-001A DETACH LEVER
5 GE30973-001A KICK LEVER
6 GE40192-001A SHAFT
7 GE40193-001A SHAFT
8 WDL123525 WASHER (x2)
9 WDL215025 WASHER (x2)
10 GE40194-001A T SPRING
11 GE40195-002A T.SPRING
12 GE40218-009A SHEET (x2)
13 GE10073-004A TOP CHASSIS
14 GE40135-001A EARTH PLATE
15 GE10074-001A BOTTOM CHASSIS
16 GE10075-001A FRONT CHASSIS
17 GE40156-001A BLIND
18 GE40224-001A MIRROR SHEET (x2)
19 GE30974-001A FPC GUIDE
20 GE40196-001A ABSORBER (x2)
21 GE31204-003A INSULATOR
22 GE31206-002A HEAT SINK
23 GE40107-002A HEAT SINK
24 QYSPSP2003M SCREW 2mm x 3mm(x2)
25 QYSPSTU2040M TAP SCREW M2 x 4mm(x2)
26 LV42181-002A SPECIAL SCREW (x2)
27 LV40865-001A MINI SCREW (x2)
28 LV40865-001A MINI SCREW (x3)
29 LV40865-001A MINI SCREW
30 LV41200-001A SPECIAL SCREW (x2)
31 QYSDST2606Z SCREW 2.6mm x 6mm(x2)
32 QYSDST2604Z SCREW 2.6mm x 4mm
33 QYSDST2604Z SCREW 2.6mm x 4mm
34 LV41200-001A SPECIAL SCREW (x2)
35 FSKZ4005-002 SCREW (x2)
36 QYSDST2610Z SCREW 2.6mm x 10mm(x2)
37 QYSDST2610Z SCREW 2.6mm x 10mm
38 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
39 QYSDST2604Z SCREW 2.6mm x 4mm(x2)
40 QYSDST2004Z SCREW 2mm x 4mm(x5)
41 GE40218-011A SHEET
42 GE10082-006A FRONT PANEL
AR30
00
42 GE10082-005A FRONT PANEL LH300
43 GE31177-002A FINDER ASSY
AR30
00
43 GE31177-001A FINDER ASSY LH300
44 GE30832-002A POWER BUTTON
45 GE30856-001A KNOB
46 GE30859-001A SEL BUTTON
47 GE30834-001A RIM LENS
48 GE30836-001A RIM COVER(L)
49 GE31200-004A RESET BUTTON
AR30
00
49 GE31200-003A RESET BUTTON LH300
50 GE20152-001A PRESET BUTTON
51 GE31172-002A EQ BUTTON
52 GE31174-004A DETACH BUTTON
AR30
00
52 GE31174-003A DETACH BUTTON LH300
53 FSKW3002-012 COMP.SPRING
54 GE30835-001A NAV BUTTON
55 FSYH4036-013 SHEET
56 GE30937-002A NAVI BASE
57 GE30858-003A RIM COVER(R)
58 GE30860-001A FM/AM BUTTON
59 GE30861-002A EQ BUTTON
60 GE31173-001A EJECT BUTTON
61 GE31203-004A R.COVER ASSY
62 VKZ4777-001 MINI SCREW (x4)
63 GE40218-006A SHEET (x2)
64 GE40218-008A SHEET
66 GE40204-001A JVC BADGE
67 GE31175-001A LCD CASE
68 GE40218-007A SHEET
69 GE30984-005A LCD LENS
70 LV33404-001A LENS CASE
71 LV42884-001A LCD FILTER
72 LV42995-002A LCD FILTER
73 LV42955-002A LENS SHEET
74 LV43084-001A DOUBLE FACE
75 LV40848-034A SPACER(P)
76 LV40846-036A SPACER(F)
77 GE31163-003A NAME PLATE
AR30
00
77 GE31160-002A NAME PLATE LH300
78 QLD0232-001 LCD MODULE
79 QUQ105-2207AE FFC WIRE
80 VYSH101-009 SPACER
81 QAM0547-001 SUBWOOFER CABEL
82 QAM0548-001 L-IN CABLE
AR30
00
83 VYTA500-001 PIN CAP (x4)
AR30
00
83 VYTA500-001 PIN CAP (x2) LH300
84 QNZ0664-001 CAR CONNECTOR
85 QAL0536-001 FPC CABLE
86 GE31205-003A REAR BRACKET
87 GE40207-001A POWER IC BKT
88 GE40208-001A REG IC BKT
89 QYSDSF2606Z SCREW 2.6mm x 6mm
90 QYSDSF2606Z SCREW 2.6mm x 6mm(x2)
91 QYSDST2604Z SCREW 2.6mm x 4mm
92 QYSDST2606Z SCREW 2.6mm x 6mm
93 GE40214-001A WIRE HOLDER
94 QYSDST2604Z SCREW 2.6mm x 4mm
95 QMFZ047-150-T FUSE 15A
96 GE20156-001A GEAR BKT UNIT
97 FSYH4036-100 SHEET
98 GE30968-001A LEVER BKT UNIT
99 GE30964-001A LOWER LEVER ASS
