JVC KD-AR760 Service Manual

3-11
Switch board(KD-AR760/G710_J)
Block No. [0][2]
X702 QAX0401-001 CRYSTAL 32.768KHz
 Symbol No. Part No. Part Name Description Local
IC601 PT6578LQ-L IC
IC602 RPM7338-V4 RM.RECEIVER
Q641 2SB624/4/-X TRANSISTOR
Q643 UN2211-X TRANSISTOR
D601 SML-310LT/MN/-X LED
D602 SML-310VT/JK/-X LED
D603 SML-310VT/JK/-X LED
D604 SML-310VT/JK/-X LED
D605 SML-310VT/JK/-X LED
D606 SML-310VT/JK/-X LED
D607 SML-310VT/JK/-X LED
D608 SML-310VT/JK/-X LED
D609 SML-310VT/JK/-X LED
D610 SML-310VT/JK/-X LED
D611 SML-310VT/JK/-X LED
D612 SML-310VT/JK/-X LED
D613 SML-310VT/JK/-X LED
D614 SML-310VT/JK/-X LED
D616 SML-310LT/MN/-X LED AR760J
D616 SML-310VT/JK/-X LED G710J
D617 SML-310VT/JK/-X LED
D618 SML-310VT/JK/-X LED
D620 SML-310LT/MN/-X LED AR760J
D620 SML-310VT/JK/-X LED G710J
D621 SML-310LT/MN/-X LED AR760J
D621 SML-310VT/JK/-X LED G710J
D622 SML-310VT/JK/-X LED
D623 SML-310VT/JK/-X LED
D631 MA111-X SI DIODE AR760J
D632 MA111-X SI DIODE AR760J
D641 NSPW310BS/BRS/ LED
D642 NSPW310BS/BRS/ LED
D643 NSPW310BS/BRS/ LED
D650 MA8091/M/-X Z DIODE
D651 MA8051/M/-X Z DIODE
D652 MA111-X SI DIODE
D653 MA111-X SI DIODE
D654 MA111-X SI DIODE
D655 MA111-X SI DIODE
D656 MA111-X SI DIODE
D657 MA111-X SI DIODE
D658 MA111-X SI DIODE
D680 MA8056/M/-X Z DIODE
C601 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C604 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C605 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C608 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C609 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C610 NBE21CM-475X TA E CAPACITOR 4.7uF 16V M
C611 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C612 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C680 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
R601 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R605 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R606 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R607 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R608 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R609 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
R610 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R611 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R612 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R613 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R614 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R615 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R622 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J G710J
R624 NRSA02J-821X MG RESISTOR 820
Ω 1/10W J
R625 NRSA02J-561X MG RESISTOR 560
Ω 1/10W J
R628 NRSA02J-821X MG RESISTOR 820
Ω 1/10W J
R630 NRSA02J-561X MG RESISTOR 560
Ω 1/10W J
R632 NRSA02J-561X MG RESISTOR 560
Ω 1/10W J
R633 NRSA02J-561X MG RESISTOR 560
Ω 1/10W J
R636 NRSA02J-561X MG RESISTOR 560
Ω 1/10W J
R638 NRSA02J-561X MG RESISTOR 560
Ω 1/10W J
R639 NRSA02J-821X MG RESISTOR 820
Ω 1/10W J
R642 NRSA02J-821X MG RESISTOR 820
Ω 1/10W J
R644 NRSA02J-561X MG RESISTOR 560
Ω 1/10W J
R645 NRSA02J-821X MG RESISTOR 820
Ω 1/10W J
R647 NRSA02J-561X MG RESISTOR 560
Ω 1/10W J
R649 NRSA02J-561X MG RESISTOR 560
Ω 1/10W J
R655 NRS181J-431X MG RESISTOR 430
Ω 1/8W J
R656 NRS181J-431X MG RESISTOR 430
Ω 1/8W J
R657 NRS181J-431X MG RESISTOR 430
Ω 1/8W J
R658 NRS181J-471X MG RESISTOR 470
Ω 1/8W J
R659 NRS181J-473X MG RESISTOR 47k
Ω 1/8W J
R660 NRS181J-102X MG RESISTOR 1k
Ω 1/8W J
R661 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J AR760J
R665 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R668 NRS181J-102X MG RESISTOR 1k
Ω 1/8W J
R669 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R670 NRSA63J-394X MG RESISTOR 390k
Ω 1/16W J
R671 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R672 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R673 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R674 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R675 NRSA63J-683X MG RESISTOR 68k
Ω 1/16W J
R676 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R677 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R678 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R679 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R680 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R681 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R685 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R690 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
CN601 NNZ0098-003X CAR CONNECTOR
JS601 QSW0793-001 ROTARY ENCODER
S601 NSW0206-001X TACT SWITCH
S602 NSW0206-001X TACT SWITCH
S603 NSW0206-001X TACT SWITCH
S605 NSW0206-001X TACT SWITCH
S606 NSW0206-001X TACT SWITCH
S607 NSW0206-001X TACT SWITCH
S608 NSW0206-001X TACT SWITCH
S609 NSW0206-001X TACT SWITCH
S610 NSW0206-001X TACT SWITCH
S611 NSW0206-001X TACT SWITCH
S612 NSW0206-001X TACT SWITCH
S613 NSW0206-001X TACT SWITCH
S614 NSW0206-001X TACT SWITCH
S615 NSW0206-001X TACT SWITCH
S616 NSW0206-001X TACT SWITCH
S617 NSW0206-001X TACT SWITCH
S690 NSW0206-001X TACT SWITCH
SD601 NSW0218-001X LUMISWITCH
SD602 NSW0218-001X LUMISWITCH
TH685 NAD0028-103X N THERMISTOR 10k
Ω
 Symbol No. Part No. Part Name Description Local

JVC KD-AR760 Specifications

General

Brand	JVC
Model	KD-AR760
Category	Car Receiver
Language	English
