Electrical parts list
Main board
Block No. [0][1]
Symbol No.
Part No. Part Name Description Local
IC161 BD3807K IC
IC251 NJM4565M-WE IC
IC271 CD4066BPW-X IC
IC301 TB2906HQ IC
IC361 NJM2160BV-X IC
IC381 NJM2160BV-X IC
IC701 UPD784218AGC303 IC
IC702 IC-PST3433U-X IC
IC703 BR24L16F-W-X IC
IC704 SN74AHCT1G08V-X IC
IC801 HD74HC126FP-X IC
IC901 HA13164A IC
IC951 BA6956AN IC
Q5 2SB624/4/-X TRANSISTOR
Q6 2SB624/4/-X TRANSISTOR
Q7 UN2211-X TRANSISTOR
Q241 2SD601A/QR/-X TRANSISTOR
Q251 2SD601A/QR/-X TRANSISTOR
Q252 UN2111-X TRANSISTOR
Q271 UN2211-X TRANSISTOR
Q272 UN2211-X TRANSISTOR
Q301 UN2211-X TRANSISTOR
Q302 2SD601A/QR/-X TRANSISTOR
AR960
Q321 KTD1304-X TRANSISTOR
Q331 KTD1304-X TRANSISTOR
Q341 KTD1304-X TRANSISTOR
Q351 KTD1304-X TRANSISTOR
Q703 UN2211-X TRANSISTOR
Q704 UN2213-X DIGI TRANSISTOR
Q705 UN2211-X TRANSISTOR
Q706 UN2211-X TRANSISTOR
Q707 UN2211-X TRANSISTOR
Q708 UN2211-X TRANSISTOR
Q781 UN2111-X TRANSISTOR
Q782 UN2111-X TRANSISTOR
Q841 UN2211-X TRANSISTOR
Q881 2SD601A/QR/-X TRANSISTOR
Q891 UN2211-X TRANSISTOR
AR960
Q901 2SB624/4/-X TRANSISTOR
Q902 UN2211-X TRANSISTOR
Q951 UN2211-X TRANSISTOR
Q976 UN2213-X DIGI TRANSISTOR
Q977 2SB709A/QR/-X TRANSISTOR
D1 MA111-X SI DIODE
D2 MA111-X SI DIODE
D3 MC2838-X DIODE
D161 MC2838-X DIODE
D241 RB160M-30-X SB DIODE
D242 MA111-X SI DIODE
D243 UDZS5.1B-X Z DIODE
D251 MA111-X SI DIODE
D252 MA111-X SI DIODE
D253 MA111-X SI DIODE
D301 MA111-X SI DIODE
D302 MA111-X SI DIODE
D321 MC2836-X DIODE
D341 MC2836-X DIODE
D701 MA111-X SI DIODE
D705 MA8062/M/-X Z DIODE
D711 SML-310VT/JK/-X LED
D712 SML-310VT/JK/-X LED
D713 SML-310VT/JK/-X LED
D715 MC2838-X DIODE
D716 MC2838-X DIODE
D717 SIR-34ST3F SI DIODE
D721 MA8062/M/-X Z DIODE
D781 MA111-X SI DIODE
D782 UDZS11B-X Z DIODE
D853 RB160M-30-X SB DIODE
D854 RB160M-30-X SB DIODE
D891 MC2836-X DIODE
AR960
D901 MA111-X SI DIODE
D902 MA111-X SI DIODE
D951 UDZS3.9B-X Z DIODE
D961 1N5401-F64 DIODE
D994 RB160M-30-X SB DIODE
D996 RB160M-30-X SB DIODE
C1 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C2 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3 QERF1AM-107Z E CAPACITOR 100uF 10V M
C4 QERF1AM-476Z E CAPACITOR 47uF 10V M
C5 QERF1AM-107Z E CAPACITOR 100uF 10V M
C6 QERF1AM-107Z E CAPACITOR 100uF 10V M
C7 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C8 NDC31HJ-331X C CAPACITOR 330pF 50V J
C9 QERF1HM-104Z E CAPACITOR 0.1uF 50V M
C81 QERF1EM-475Z E CAPACITOR 4.7uF 25V M
C82 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C91 QERF1EM-475Z E CAPACITOR 4.7uF 25V M
C92 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C141 NCB31EK-472X C CAPACITOR 4700pF 25V K
AR960
C142 QERF1HM-105Z E CAPACITOR 1uF 50V M
AR960
C143 QERF1HM-105Z E CAPACITOR 1uF 50V M
AR960
C144 NCB21CK-474X C CAPACITOR 0.47uF 16V K
AR960
C151 NCB31EK-472X C CAPACITOR 4700pF 25V K
AR960
C152 QERF1HM-105Z E CAPACITOR 1uF 50V M
AR960
C161 QERF1HM-105Z E CAPACITOR 1uF 50V M
C162 QTE1H55-225Z E CAPACITOR 2.2uF 50V
C163 QERF1HM-105Z E CAPACITOR 1uF 50V M
C164 NCB31HK-221X C CAPACITOR 220pF 50V K
C165 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C166 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C167 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C168 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C169 QERF1AM-107Z E CAPACITOR 100uF 10V M
C181 QERF1HM-105Z E CAPACITOR 1uF 50V M
C182 QTE1H55-225Z E CAPACITOR 2.2uF 50V
C183 QERF1HM-105Z E CAPACITOR 1uF 50V M
C184 NCB31HK-221X C CAPACITOR 220pF 50V K
C185 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C186 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C187 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C188 QERF1CM-106Z E CAPACITOR 10uF 16V M
C189 QERF1CM-106Z E CAPACITOR 10uF 16V M
C190 NCB31EK-123X C CAPACITOR 0.012uF 25V K
C242 QERF1HM-105Z E CAPACITOR 1uF 50V M
C243 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C244 QERF1CM-226Z E CAPACITOR 22uF 16V M
C245 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C251 NCB31HK-682X C CAPACITOR 6800pF 50V K
AR960
C251 NCB31HK-822X C CAPACITOR 8200pF 50V K LH910
C252 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C253 QERF1CM-106Z E CAPACITOR 10uF 16V M
C255 QERF1CM-106Z E CAPACITOR 10uF 16V M
C256 NCB31EK-823X C CAPACITOR 0.082uF 25V K
C257 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C259 QERF0JM-476Z E CAPACITOR 47uF 6.3V M
C271 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C272 NCB31HK-562X C CAPACITOR 5600pF 50V K
C273 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C274 NCB31EK-273X C CAPACITOR 0.027uF 25V K
C275 NCB31EK-273X C CAPACITOR 0.027uF 25V K
C301 NFV81CM-105X MF CAPACITOR 1uF 16V M
C302 NFV81CM-105X MF CAPACITOR 1uF 16V M
C303 NDC31HJ-101X C CAPACITOR 100pF 50V J
C304 NDC31HJ-101X C CAPACITOR 100pF 50V J
C305 NCB31HK-472X C CAPACITOR 4700pF 50V K
C306 NCB31HK-472X C CAPACITOR 4700pF 50V K
C307 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C308 QERF1EM-475Z E CAPACITOR 4.7uF 25V M
C311 NFV81CM-105X MF CAPACITOR 1uF 16V M
C312 NFV81CM-105X MF CAPACITOR 1uF 16V M
C313 NDC31HJ-101X C CAPACITOR 100pF 50V J
C314 NDC31HJ-101X C CAPACITOR 100pF 50V J
C315 NCB31HK-472X C CAPACITOR 4700pF 50V K
