Front end board(Only DVH426)
Block No. [1][2]
R358 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R361 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R362 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R363 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R364 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R365 NRSA63D-911X MG RESISTOR 910 Ω 1/16W D
R366 NRSA63D-202X MG RESISTOR 2k Ω 1/16W D
R370 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R371 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R372 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R373 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R374 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R380 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R384 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R385 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R386 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R390 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R396 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R399 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R401 NRSA63J-100X MG RESISTOR 10 Ω 1/16W J
R402 NRSA63J-4R7X MG RESISTOR 4.7 Ω 1/16W J
R403 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R404 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R411 NRSA63J-100X MG RESISTOR 10 Ω 1/16W J
R421 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R422 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R431 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R432 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R433 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R434 NRSA63J-201X MG RESISTOR 200 Ω 1/16W J
R435 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R436 NRSA63J-201X MG RESISTOR 200 Ω 1/16W J
R437 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R438 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R441 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R442 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R481 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R491 NRSA63D-472X MG RESISTOR 4.7k Ω 1/16W D
R492 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R521 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R522 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R531 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R532 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R533 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R534 NRSA63J-201X MG RESISTOR 200 Ω 1/16W J
R535 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R536 NRSA63J-201X MG RESISTOR 200 Ω 1/16W J
R537 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R538 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R621 NQL093K-1R8X COIL 1.8uH K
L303 NQL044K-100X COIL 0.26 Ω 10uH K
L305 NQL093K-1R8X COIL 1.8uH K
L306 NQL093K-1R8X COIL 1.8uH K
L307 NQL093K-1R8X COIL 1.8uH K
L451 NQL044K-100X COIL 0.26 Ω 10uH K
CN101 QGF0501F8-30X CONNECTOR FFC/FPC (1-30)
CN201 QGF1038F2-11X CONNECTOR FFC/FPC (1-11)
CN202 QGF0523F2-05W CONNECTOR FFC/FPC (1-5)
CN402 QGF0522F3-06W CONNECTOR FFC/FPC (1-6)
CN403 QGF0534F3-45X CONNECTOR FFC/FPC (1-45)
K101 NQR0007-002X FERRITE BEADS
K102 NQR0007-002X FERRITE BEADS
K301 NQR0502-001X FERRITE BEADS
K311 NQR0129-002X FERRITE BEADS
K399 NQR0502-001X FERRITE BEADS
K401 NQR0022-005X FERRITE BEADS
K402 NQR0022-005X FERRITE BEADS
K404 NQR0022-005X FERRITE BEADS
K405 NQR0022-005X FERRITE BEADS
K406 NQR0022-005X FERRITE BEADS
K407 NQR0022-005X FERRITE BEADS
K425 NQL093K-1R8X COIL 1.8uH K
K435 NQR0022-005X FERRITE BEADS
K441 NQR0022-005X FERRITE BEADS
K442 NQR0022-005X FERRITE BEADS
K443 NQR0022-005X FERRITE BEADS
 Symbol No. Part No. Part Name Description Local
K444 NQR0022-005X FERRITE BEADS
K445 NQR0022-005X FERRITE BEADS
K451 NQR0022-005X FERRITE BEADS
K452 NQR0022-005X FERRITE BEADS
K601 NQR0022-005X FERRITE BEADS
SW4 NSW0184-001X DETECT SW
SW5 NSW0183-001X DETECT SW
TH491 NAD0025-103X N THERMISTOR 10k Ω
X351 NAX0741-001X CRYSTAL 27.000MHz
 Symbol No. Part No. Part Name Description Local
IC201 BA5835FM-X IC
IC251 BD6671FM-X IC
 IC301 MN2DS0003AA-H IC
IC302 BA00HC5WF-X IC
IC304 S-80827CNNB-G-W IC
IC398 SG32A90TFIR32C IC(PROGRAMED)
IC399 K4S281632F-UC75 IC(DIGITAL)
IC399 or EDS1216AATA-75 IC(DIGITAL)
IC401 AK4385ET-X IC
IC411 NJM4580V-X IC
IC481 BR93L66F-W-X IC(DIGITAL)
Q101 2SB1424/R/-W TRANSISTOR
Q102 2SC4617/R/-X TRANSISTOR
Q103 2SB1424/R/-W TRANSISTOR
Q104 2SC4617/R/-X TRANSISTOR
Q105 2SK3019-X MOS FET
Q106 2SK3019-X MOS FET
Q107 2SC4617/R/-X TRANSISTOR
Q231 DTC114EE-X DIGI TRANSISTOR
Q301 DTC144EE-X DIGI TRANSISTOR
Q302 DTC144EE-X DIGI TRANSISTOR
C1 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C8 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C9 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C10 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C11 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C12 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C13 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C14 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C15 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C16 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C17 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C18 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C19 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C20 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C21 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C102 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C103 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C104 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C105 NBE41AM-476X TA E CAPACITOR 47uF 10V M
C106 NBE41AM-476X TA E CAPACITOR 47uF 10V M
C108 NBE41AM-476X TA E CAPACITOR 47uF 10V M
C111 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C112 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C113 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C201 NEAF1CM-107X E CAPACITOR 100uF 16V M
C202 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C203 NCS31HJ-271X C CAPACITOR 270pF 50V J
C204 NDC31HJ-151X C CAPACITOR 150pF 50V J
C205 NCB31HK-681X C CAPACITOR 680pF 50V K
C206 NCB31HK-561X C CAPACITOR 560pF 50V K
 Symbol No. Part No. Part Name Description Local
