(No.MA038)1-27
5.5 Signal processing section
No sound from either
channel.
Is 9V present at IC161 pin
31?
Compare the L-ch and
R-ch to locate the
defctive point.
Is the sound output from
both channels (L, R)?
Check the viciniyt of the
IC901 audio power
supply.
NO
NONO
NO
YES
YES
YES
YES
YES
Check IC581 and its
peripheral circuits.
Is the audio signal
(including sampling output
components) output to
IC581 pins 1 and 7 during
playback?
Is the audio signal output
at IC161 pins16 and 17
during playback?
NO
Check IC161 and its
peripheral circuits.
Check the muting circuit.
Normal

Other manuals for JVC KD-G501

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the JVC KD-G501 and is the answer not in the manual?

JVC KD-G501 Specifications

Audio Amplifier Specifications IconAudio Amplifier Specifications
maximum power output front50 W per channel
maximum power output rear50 W per channel
continuous power output front19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
continuous power output rear19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
load impedance4 Ω (4 Ω to 8 Ω allowance)
tone control range bass±10 dB at 100 Hz
tone control range treble±10 dB at 10 kHz
frequency response40 Hz to 20 000 Hz
signal-to-noise ratio70 dB
line-out level/impedance2.0 V/20 kΩ load (full scale)
output impedance1 kΩ
CD Player Specifications IconCD Player Specifications
operating voltageDC 14.4 V (11 V to 16 V allowance)
allowable operating temperature0°C to +40°C
dimensions installation size182 mm × 52 mm × 150 mm
dimensions panel size188 mm × 58 mm × 12 mm
mass1.4 kg (excluding accessories)
frequency response5 Hz to 20 000 Hz
dynamic range96 dB
signal-to-noise ratio98 dB
max. bit rate320 Kbps
Tuner Specifications IconTuner Specifications
frequency range FM87.5 MHz to 108.0 MHz
frequency range AM (MW)522 kHz to 1 620 kHz
frequency range AM (LW)144 kHz to 279 kHz
usable sensitivity FM11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity FM16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (400 kHz) FM65 dB
frequency response FM40 Hz to 15 000 Hz
stereo separation FM30 dB
capture ratio FM1.5 dB
sensitivity MW20 µV
selectivity MW35 dB
sensitivity LW50 µV
