Audio Amplifier Specifications| maximum power output front | 50 W per channel |
|---|---|
| maximum power output rear | 50 W per channel |
| continuous power output front | 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion |
| continuous power output rear | 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion |
| load impedance | 4 Ω (4 Ω to 8 Ω allowance) |
| tone control range bass | ±10 dB at 100 Hz |
| tone control range treble | ±10 dB at 10 kHz |
| frequency response | 40 Hz to 20 000 Hz |
| signal-to-noise ratio | 70 dB |
| line-out level/impedance | 2.0 V/20 kΩ load (full scale) |
| output impedance | 1 kΩ |
CD Player Specifications| operating voltage | DC 14.4 V (11 V to 16 V allowance) |
|---|---|
| allowable operating temperature | 0°C to +40°C |
| dimensions installation size | 182 mm × 52 mm × 150 mm |
| dimensions panel size | 188 mm × 58 mm × 12 mm |
| mass | 1.4 kg (excluding accessories) |
| frequency response | 5 Hz to 20 000 Hz |
| dynamic range | 96 dB |
| signal-to-noise ratio | 98 dB |
| max. bit rate | 320 Kbps |
Tuner Specifications| frequency range FM | 87.5 MHz to 108.0 MHz |
|---|---|
| frequency range AM (MW) | 522 kHz to 1 620 kHz |
| frequency range AM (LW) | 144 kHz to 279 kHz |
| usable sensitivity FM | 11.3 dBf (1.0 µV/75 Ω) |
| 50 dB quieting sensitivity FM | 16.3 dBf (1.8 µV/75 Ω) |
| alternate channel selectivity (400 kHz) FM | 65 dB |
| frequency response FM | 40 Hz to 15 000 Hz |
| stereo separation FM | 30 dB |
| capture ratio FM | 1.5 dB |
| sensitivity MW | 20 µV |
| selectivity MW | 35 dB |
| sensitivity LW | 50 µV |
