JVC KD-G501 Service Manual

3-15
Packing and Accessories
Block No. [M][3][M][M]
 Symbol No. Part No. Part Name Description Local
A 1 GET0193-001A INST BOOK
ENG GER FRE
DUT
G501
E,G50
1EX
A 1 GET0194-001A INST BOOK ENG RUS
G507
EE
A 2 GET0193-002A INST BOOK SPA ITA POL RUS
G501
E
A 2 GET0193-003A INST BOOK
SWE DAN FIN
GRE
G501
EX
A 3 GET0193-005A INSTALL MANUAL
ENG GER FRE
DUT
G501
E,G50
1EX
A 3 GET0194-002A INSTALL MANUAL ENG RUS
G507
EE
A 4 GET0193-006A INSTALL MANUAL SPA ITA POL RUS
G501
E
A 4 GET0193-007A INSTALL MANUAL
SWE DAN FIN
GRE
G501
EX
A 5 GET0208-002A DEMO MODE SHT
G501
EX
A 5 GET0208-001A DEMO MODE SHT
G501
E,G50
7EE
A 6 LVT1120-002A MP3 GUIDE
G501
E,G50
1EX
A 6 LVT1120-004A MP3 GUIDE
G507
EE
A 7 BT-54013-7 WARRANTY CARD
A 8 VND3050-002 IDENTITY CARD
G501
E,G50
1EX
A 9 VND3046-001 SERIAL TICKET
A 10 VKZ4027-202 PLUG NUT
A 11 VKH4871-001SS MOUNT BOLT
A 12 VKZ4328-001 LOCK NUT
A 13 WNS5000Z WASHER
A 14 GE40130-002A HOOK (x2)
A 15 FSJB3002-00C HARD CASE
A 16 GE20137-003A MOUNTING SLEEVE
A 17 GE20149-007A TRIM PLATE
A 18 QAM0176-002 POWER CORD
KIT KSFX480K-SCREW1 SCREW PARTS KIT
A10 A11 A12 A13
A14
P 1 FSPG4002-001 POLY BAG (x2)
G501
E,G50
1EX
P 1 FSPG4002-001 POLY BAG
G507
EE
P 2 QPA00801205 POLY BAG 8cm x 12cm
P 3 FSYH4036-068 SHEET
P 4 QPA01003003 POLY BAG 10cm x 30cm
P 5 QPC03004315P POLY BAG 30cm x 43cm
P 6 GE31134-002A CARTON
G501
E,G50
1EX
P 6 GE31287-001A CARTON
G507
EE
P 7 GE10070-002A EPS CUSHION

JVC KD-G501 Specifications

Audio Amplifier Specifications

maximum power output front	50 W per channel
maximum power output rear	50 W per channel
continuous power output front	19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
continuous power output rear	19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
load impedance	4 Ω (4 Ω to 8 Ω allowance)
tone control range bass	±10 dB at 100 Hz
tone control range treble	±10 dB at 10 kHz
frequency response	40 Hz to 20 000 Hz
signal-to-noise ratio	70 dB
line-out level/impedance	2.0 V/20 kΩ load (full scale)
output impedance	1 kΩ

CD Player Specifications

operating voltage	DC 14.4 V (11 V to 16 V allowance)
allowable operating temperature	0°C to +40°C
dimensions installation size	182 mm × 52 mm × 150 mm
dimensions panel size	188 mm × 58 mm × 12 mm
mass	1.4 kg (excluding accessories)
frequency response	5 Hz to 20 000 Hz
dynamic range	96 dB
signal-to-noise ratio	98 dB
max. bit rate	320 Kbps

Tuner Specifications

frequency range FM	87.5 MHz to 108.0 MHz
frequency range AM (MW)	522 kHz to 1 620 kHz
frequency range AM (LW)	144 kHz to 279 kHz
usable sensitivity FM	11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity FM	16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (400 kHz) FM	65 dB
frequency response FM	40 Hz to 15 000 Hz
stereo separation FM	30 dB
capture ratio FM	1.5 dB
sensitivity MW	20 µV
selectivity MW	35 dB
sensitivity LW	50 µV
