25
ENGLISH
To go to a particular file quickly within the
current folder (+10 and –10 buttons)
1 Press MODE to enter the functions mode
while playing a disc.
2 Press +10 or 10.
* First time you press +10 or 10 button, the
file skips to the nearest higher or lower file
with a file number of multiple ten (ex. 10th,
20th, 30th).
Then each time you press the button, you can
skip 10 files (see How to use the +10 and
10 buttons below).
After the last file, the first file will be selected,
and vice versa.
How to use the +10 and –10 buttons
Ex. 1: To select file number 32 while playing
file number 6
Ex. 2 :To select file number 8 while playing
file number 36
(Three times) (Twice)
File 6 \ 10 \ 20 \ 30 \ 31 \ 32
File 36 \ 30 \ 20 \ 10 \ 9 \ 8
(Three times) (Twice)
To skip 10 files* forwards to
the last file
To skip 10 files* backwards to
the first file
To go to a particular folder directly
IMPORTANT:
To directly select the folders using the number
button(s), it is required that folders are
assigned 2 digit numbers at the beginning of
their folder names. (This can only be done
during the recording of CD-Rs or CD-RWs.)
Ex.: If folder name is 01 ABC
= Press 1 to go to Folder 01 ABC.
If folder name is 1 ABC, pressing 1
does not work.
If folder name is 12 ABC
= Press and hold 6 (12) to go to Folder
12 ABC.
Press the number button corresponding to the
folder number to start playing the first file in the
selected folder.
To select a folder number from 01 06:
Press 1 (7) 6 (12) briefly.
To select a folder number from 07 12:
Press and hold 1 (7) 6 (12) for more than one
second.
Notes:
If indicator flashes on the display after you have
selected a folder, it means that the folder does not
contain any MP3 files.
You cannot directly select a folder with a number
greater than 12.
To select a particular file in a folder, press
¢ or 4 after selecting the folder.
CONTINUED ON THE NEXT PAGE
EN23-26_KD-G501[E_EX_EU]f.p65 10/4/03, 2:34 PM25

Other manuals for JVC KD-G501

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the JVC KD-G501 and is the answer not in the manual?

JVC KD-G501 Specifications

Audio Amplifier Specifications IconAudio Amplifier Specifications
maximum power output front50 W per channel
maximum power output rear50 W per channel
continuous power output front19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
continuous power output rear19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
load impedance4 Ω (4 Ω to 8 Ω allowance)
tone control range bass±10 dB at 100 Hz
tone control range treble±10 dB at 10 kHz
frequency response40 Hz to 20 000 Hz
signal-to-noise ratio70 dB
line-out level/impedance2.0 V/20 kΩ load (full scale)
output impedance1 kΩ
CD Player Specifications IconCD Player Specifications
operating voltageDC 14.4 V (11 V to 16 V allowance)
allowable operating temperature0°C to +40°C
dimensions installation size182 mm × 52 mm × 150 mm
dimensions panel size188 mm × 58 mm × 12 mm
mass1.4 kg (excluding accessories)
frequency response5 Hz to 20 000 Hz
dynamic range96 dB
signal-to-noise ratio98 dB
max. bit rate320 Kbps
Tuner Specifications IconTuner Specifications
frequency range FM87.5 MHz to 108.0 MHz
frequency range AM (MW)522 kHz to 1 620 kHz
frequency range AM (LW)144 kHz to 279 kHz
usable sensitivity FM11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity FM16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (400 kHz) FM65 dB
frequency response FM40 Hz to 15 000 Hz
stereo separation FM30 dB
capture ratio FM1.5 dB
sensitivity MW20 µV
selectivity MW35 dB
sensitivity LW50 µV
