KD-LX330R/KD-LX110R
1-15
EXTGS004-26P
EXTLX001-2P
EXTLX001-6PC
EXTLX001-6PF
EXTLX001-16PF
EXTLX002-4P
EXTLX002-SWPWB
EXTLX002-16PC
EXTLX001-2P
Extension cord list
EXTLX002-JIG : Kit including the following 8 extension parts.
1
2
3
4
5
6
7
2
1
1
1
1
1
1
2Pin, 30cm extension cord
6Pin, 30cm flat wire
6Pin x 2, interlocking connector
16Pin flat wire
16Pin, interlocking connector
3 switch PWB
4Pin, 30cm extension cord
EXTLX001-2P
EXTLX001-6PF
EXTLX001-6PC
EXTLX002-16PF
EXTLX002-16PC
EXTLX002-SWPWB
EXTLX002-4P
No.
Parts number Quantity Description
Besides the above kit, we offer the conventional extension cord for CD mechanism
which are not essential to operation check or service. The mechanism should be
directly connected to the board using the extension wire. EXTGS004-26P
