KD-LX110R/KD-LX330R
3-17
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M3MM
P 1 QPC03004315P POLY BAG 1 KD-LX330R
P 2 PDB450089 GIFT BOX 1 KD-LX110R
PDB450088 GIFT BOX 1 KD-LX330R
P 3 LV10193-201A PAPER CUSHION 2
P 4 FSPG4002-001A POLLY BAG 2
P 5 QPA00801205 POLY BAG 1
(Packing)
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M4MM
A 1 PIM165800 INSTRUCTION 1 KD-LX110R SPA ITA SWE
PIM165900 INSTRUCTION 1 KD-LX330R SPA ITA SWE
PIM164200 INSTRUCTION 1 KD-LX330R ENG GER FRE
PIM164100 INSTRUCTION 1 KD-LX110R ENG GER FRE
A 2 PIM164300 INSTALLATION 1 KD-LX110R ENG GER FRE DUT
PIM164000 INSTALLATION 1 SPA ITA SWE FIN
A 4 LV40978-001A CAUTION SHEET 1
A 5 PTC003900 CAUTION SHEET 1
A 6 BT-54013-1 WARRANTY CARD 1
A 7 VND3050-001 IDENTITY CARD 1
A 10 FSKM2004-202 MOUNTING SLEEVE 1
A 11 LV10187-001A-S TRIM PLATE 1
A 12 000393470 JACK COVER 3 KD-LX330R
000393470 JACK COVER 1 KD-LX110R
A 14 RM-RK31 REMOCON 1 KD-LX330R
A 15 QAB0014-001 BATTERY 1 KD-LX330R
A 16 VKZ4027-202 PLUG NUT 1
A 17 VKH4871-001 MOUNT BOLT 1
A 18 VKZ4328-001 LOCK NUT 1
A 19 FSKL4010-002 HOOK 2
A 20 WNS5000Z WASHER 1
A 21 PCT004100 TRANSPORT SHEET 1
A 22 EX0000494 ISO CORD ASS'Y 1
KIT KDGS717K-SCREW1 SCREW PARTS KIT 1
(Accessories)
