KD-LX110/KD-LX330KD-LX110/KD-LX330
3-4
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M1MM
1 DG1002000 CHASSIS TOP 1
2 DG4114000 INSULATOR
SHAS 1
3 --------- CD MECHA 1
4 QYSDST2604Z SCREW 3
5 DG4003020 FFC P.MECHA 1
6 QYSPST2004M SCREW 1
7 DG1069001 FRONT COVER 1
8 LV40828-002A BLIND 1
9 QYSPSP2003M SCREW 2
10 LV31605-001A DOOR BASE ASS'Y 1
11 DG4112010 PANEL COVER ASS 1
12 LV31610-001A ROD GEAR 1
13 DG1073150 BUTTON PANEL 1 KD-LX110R
DG1073151 BUTTON PANEL 1 KD-LX330R
14 DG3024000 BUTTON BASE BKT 1
15 DG4071010 BUTTON B SUPORT 1
16 YM2029000 SCREW 3
17 LV41452-003A TENS SPRING BTM 2
19 YM2029000 SCREW 4
20 DG1122001 DISPLAY PANEL 1
21 XP1728P3B SCREW 4
22 EX0000496 17P FLAT CABLE 1
23 XT2640BSC SCREW 8
24 DG3008000 SIDE HEAT SINK 1
25 XT26A0BPC SCREW 1
26 YM2626002 SCREW 4
27 YM2626000 SCREW 1
28 LV41469-001A UP DOWN B.ASS'Y 1
29 LV40848-009A SPACER
P
1
30 LV40846-005A SPACER
F
1
31 DG3126020 KNOB SPRING 1
32 DG4127010 ENCODER PLATE 1
33 DG3121050 KNOB VOL ASSY 1
34 VKZ4777-001 MINI SCREW 4
35 DG3102010 FINDER ASSY 1
36 DG4136000 D.P. PLATE 1
37 LV41505-001A REMOTE LENS 1
38 QAR0029001-SA2 MOTOR ASS'Y 1
39 LV40847-002A SPACER 1
40 KA2502009 2P CONECTOR ASS 1
41 DG4138000 MOTOR ASS'Y 1
42 LV40847-002A SPACER 1
43 KA2502010 2P CONECTOR ASS 1
44 DG3131010 MOVE BKT ASS'Y 1
45 XP2020P1C SCREW 4
46 DG3082030 PUSH LEVER ASSY 1
47 LV41466-001A GEAR 4 1
48 LV41467-001A GEAR 5 1
(General assembly)
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M1MM
49 LV30981-005A CLUTCH ASS'Y 1
50 YWP020300 C.WASHER 7
51 YWP020301 C.WASHER 2
52 LV31611-001A GEAR 3 1
53 LV41464-001A GEAR 2 1
54 LV41463-001A GEAR 1 1
55 LV30981-007A *CLUTCH ASS'Y 1
56 DG4087040 LEVER SPRING 1
57 DG3058000 FFC GUIDE 1
58 DG3010010 BOTTOM ASSY 1
59 LV41545-001A BUTTON B.GUIDE 1
60 YM2029000 SCREW 1
61 DG3014000 INSULATOR 1
62 YM2626000 SCREW 3
64 DG3092020 LIGHTING CASE 1
65 DG4090030 LCD FILTER 1
66 000101380 LCD 1 KD-LX110R
000101390 LCD 1 KD-LX330R
67 DG3089020 LCD CASE 1
68 DG4091020 ZEBRA CONTACT 2
69 EX0000495 6P FLAT CABLE 1
70 DG2074031 BUTTON PRESET 1 1
71 DG3075042 BUTTON PRESET 2 1
72 DG3076040 BUTTON SOURCE 1
73 DG1072090 BUTTON BASE 1
74 LV41825-004A PLATE SPRING 1
75 VKZ4777-004 MINI SCREW 6
76 DG3070000 REG.IC BRACET 1
77 DG4117000 POWER IC BKT 1
78 DG3005030 REAR BRACKET 1
79 DG3007010 REAR HEAT SINK 1
80 XT2640BSC SCREW 1
81 YM2626001 SCREW 3
82 XT2640BSC SCREW 2
83 FU15R0031 AUTO FUSE
1
15A
84 PLN122900 NAME LABEL 1 KD-LX110R
PLN123000 NAME LABEL 1 KD-LX330R
85 DG4115000 SHEET 2
87 DG3111000 LEAD PLATE 1
89 EX0000490 RCA CORD ASSY 1 KD-LX330R
EX0000488 RCA CORD ASSY 1 KD-LX110R
90 DG4116010 SHEET
FRONT BK 1
91 XT2040BSC SCREW 1
92 EX0000508 WIRE ASS'Y 1
94 DG4124000 SPACER 1
(General assembly)
