KD-LX110R/KD-LX330R
3-7
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M2MM
72 68150232T CONNECTOR 1 TKC-W26X-C1
79 30311105T SOPPORT PLATE 1
80 30311138T GR MT BLK
N
1
81 30311109T LDG GEAR
2
1
82 30311110T LDG GEAR
3
1
84 30311112T LDG GEAR
5
1
86 30311136T LDG ROLLER 2
88 30311118T L.P SPRING
L
1
89 30311119T L.P SPRING
R
1
90 30311123T SW PCB 1
91 30311124T SW ACTUATOR 1
92 30311129T LDG BELT 1
93 30311140T FRONT BRKT
J
1
100 9C0620503T C B TAP SCREW 2 M2X5
101 9C2020401T C SCREW TS.G 5 M2X4
102 9C4320403T C B TAP SCREW 4 M2X4
103 9C0117223T SCREW 2 M1.7X2.2
104 9C0917703T C TAP SCREW S3 1 M1.7X7
105 9C0320201T C TAP SCREW S3 1 M2X2
106 9C4920013T C TAP SCREW S3 2 M2X10
107 9C4920603T C TAP SCREW B3 4 M2X6
108 9P0220031T TAMS SCREW 2 M2X3
110 9C0420253 C TAP SCREW 1 M2X2.5
113 9W0330276 NW BLUE 2 2.9X5X0.3
116 9W0725030T LUMILAR W 1 2.3X9.8X0.25
117 9W0640030T WASHER 1 1.4X3.2X0.4
130 303105310T FEED MO ASSY 1
131 303105311T SPINDLE MO ASSY 1
132 303105312T FEED SCREW ASSY 1
133 303111301T LDG MOTOR ASSY 1
134 303111302T RDG RLR SFT ASY 1
135 303105502T T.T.BASE ASSY 1
(CD mechanism)
