KD-LX110R/KD-LX330R
3-14
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
A
C 601 CY475316J CAPACITOR CY 4.7 UF
C 602 CY104423J CAPACITOR CY 0.1 UF
C 603 CY104423J CAPACITOR CY 0.1 UF
C 604 CY102623J CAPACITOR CY 0.001 UF
C 605 CY475316J CAPACITOR CY 4.7 UF
C 606 CY104423J CAPACITOR CY 0.1 UF
C 607 CY104423J CAPACITOR CY 0.1 UF
C 608 CY102623J CAPACITOR KD-LX110R
C 608 CY104423J CAPACITOR KD-LX330R
C 609 CZ1016D2J CAPACITOR KD-LX330R
C 610 CY475316J CAPACITOR KD-LX330R
C 611 CY475316J CAPACITOR CY 4.7 UF
C 612 CQ393628J CAPACITOR C
0.039 UF
C 613 CY180J90J CAPACITOR CY 18 PF
C 614 CY104423J CAPACITOR CY 0.1 UF
C 615 CY562623J CAPACITOR CY 0.0056UF
C 616 CY475316J CAPACITOR CY 4.7 UF
C 623 CY475316J CAPACITOR CY 4.7 UF
CN601 KZ040170L CONNECTOR 17P FPC CONNECT
CN631 KZ040060L CONNECTOR 6P FPC CONNECTO
D 623 000372400-T DIODE LED SML310LT
D 624 000372400-T DIODE LED SML310LT
D 625 UDZS5.1B ZENER DIODE
D 626 DI1SS400L DIODE
D 627 000372390-T DIODE LED LT1F67AF
D 628 000372400-T DIODE LED SML310LT
D 629 000372400-T DIODE LED SML310LT
D 630 000372400-T DIODE LED SML310LT
D 631 CL-190UB-X-X DIODE LED CL-190UB-X
D 632 000372400-T DIODE LED SML310LT
D 633 000372400-T DIODE LED SML310LT
D 634 000372400-T DIODE LED SML310LT
D 635 000372400-T DIODE LED SML310LT
D 636 000372400-T DIODE LED SML310LT
D 637 000372410-T DIODE LED CL-190SD-X
D 638 000372410-T DIODE LED CL-190SD-X
D 639 000372410-T DIODE LED CL-190SD-X
D 640 000372410-T DIODE LED CL-190SD-X
D 641 000372410-T DIODE LED CL-190SD-X
D 642 000372410-T DIODE LED CL-190SD-X
D 643 000372410-T DIODE LED CL-190SD-X
D 644 000372410-T DIODE LED CL-190SD-X
D 645 000372410-T DIODE LED CL-190SD-X
D 646 000372410-T DIODE LED CL-190SD-X
D 647 000372410-T DIODE LED CL-190SD-X
D 648 000372410-T DIODE LED CL-190SD-X
D 650 CL-190UB-X-X DIODE LED CL-190UB-X
FL611 000282950 CFL CFL
IC601 TA2147F-X IC
IC602 LC75823W IC KD-LX110R
IC602 LC75811W I.C(M) KD-LX330R
IC603 RPM6938-SV4 IC IC RPM6938-V4
L 611 LC680J26L CHOKE COIL CHOKE COIL 68UH
L 612 000125810 COIL TRANS TR11-B-S
L 613 LC100K10J COIL CHOKE COIL 10UH
PC601 000874550 IC IC PR-20
611 2SD2150/RS/-W POW TRANSISTOR
612 2SD2150/RS/-W POW TRANSISTOR
691 2SC4081/QR/-X TRANSISTOR
692 2SC4081/QR/-X TRANSISTOR
R 601 RK103JA0J RESISTOR RK 1/10W 10K
R 602 RK103JA0J RESISTOR RK 1/10W 10K
R 603 RK103JA0J RESISTOR RK 1/10W 10K
R 604 RK473JA0J RESISTOR RK 1/10W 47K
R 605 RK103JA0J RESISTOR RK 1/10W 10K
R 606 RK103JA0J RESISTOR RK 1/10W 10K
R 607 RK103JA0J RESISTOR RK 1/10W 10K
R 608 RK473JA0J RESISTOR KD-LX110R
R 608 RK103JA0J RESISTOR KD-LX330R
R 609 RK153JA0J RESISTOR KD-LX330R
R 611 RK472JA0J RESISTOR RK 1/10W 4.7K
R 612 RK472JA0J RESISTOR RK 1/10W 4.7K
R 613 RK681JA0J RESISTOR RK 1/10W 680
R 621 RK271JA0J RESISTOR RK 1/10W 270
R 622 RK331JA0J RESISTOR RK 1/10W 330
R 623 RK821JA0J RESISTOR RK 1/10W 820
R 624 RK821JA0J RESISTOR RK 1/10W 820
R 625 RK471JA0J RESISTOR RK 1/10W 470
R 626 RK103JA0J RESISTOR RK 1/10W 10K
R 627 RK121JA0J RESISTOR RK 1/10W 120
R 628 RK000JA0J RESISTOR RK 1/10W 0
R 629 RK471JA0J RESISTOR RK 1/10W 470
R 630 RK271JA0J RESISTOR RK 1/10W 270
R 631 RK391JA0J RESISTOR RK 1/10W 390
R 632 RK221JA0J RESISTOR RK 1/10W 220
R 633 RK221JA0J RESISTOR RK 1/10W 220
R 634 RK221JA0J RESISTOR RK 1/10W 220
R 635 RK221JA0J RESISTOR RK 1/10W 220
R 636 RK821JA0J RESISTOR RK 1/10W 820
R 638 RK122JA0J RESISTOR RK 1/10W 1.2K
R 639 RK182JA0J RESISTOR RK 1/10W 1.8K
R 640 RK272JA0J RESISTOR RK 1/10W 2.7K
R 641 RK392JA0J RESISTOR RK 1/10W 3.9K
R 642 RK821JA0J RESISTOR RK 1/10W 820
R 643 RK821JA0J RESISTOR RK 1/10W 820
R 644 RK122JA0J RESISTOR RK 1/10W 1.2K
R 645 RK182JA0J RESISTOR RK 1/10W 1.8K
R 646 RK272JA0J RESISTOR RK 1/10W 2.7K
R 647 RK392JA0J RESISTOR RK 1/10W 3.9K
R 648 RK271JA0J RESISTOR RK 1/10W 270
R 649 RK271JA0J RESISTOR RK 1/10W 270
R 650 RK391JA0J RESISTOR RK 1/10W 390
R 651 RK221JA0J RESISTOR RK 1/10W 220
R 652 RK221JA0J RESISTOR RK 1/10W 220
R 658 RK181JA0J RESISTOR RK 1/10W 180
R 667 RK104JA0J RESISTOR RK 1/10W 100K
R 668 RK104JA0J RESISTOR RK 1/10W 100K
R 671 RK331JA0J RESISTOR RK 1/10W 330
R 672 RK331JA0J RESISTOR RK 1/10W 330
R 673 RK332JA0J RESISTOR RK 1/10W 3.3K
R 674 RK332JA0J RESISTOR RK 1/10W 3.3K
R 675 RK332JA0J RESISTOR RK 1/10W 3.3K
R 676 RK181JA0J RESISTOR RK 1/10W 180
R 691 RK104JA0J RESISTOR RK 1/10W 100K
R 692 RK393JA0J RESISTOR RK 1/10W 39K
R 693 RK104JA0J RESISTOR RK 1/10W 100K
R 694 RK393JA0J RESISTOR RK 1/10W 39K
RR637 RK821JA0J RESISTOR RK 1/10W 820
S 623 000392870-T SWITCH TACT SW LS8J2
S 624 000392870-T SWITCH TACT SW LS8J2
S 625 000392910-T SWITCH TACT SW
S 631 000392870-T SWITCH TACT SW LS8J2
S 632 000392870-T SWITCH TACT SW LS8J2
S 633 000392870-T SWITCH TACT SW LS8J2
S 634 000392870-T SWITCH TACT SW LS8J2
S 635 000392870-T SWITCH TACT SW LS8J2
(Front board)
