KD-LX333
3-8
Item
Parts number Parts name Ar
ea
Electrical parts list (Main board)
Remarks
Block No. 01
A
Item
Parts number Parts name Ar
ea
Remarks
A
BZ791 000393760 BUZZER CD11PA-XZ
CN301 KN2507297 CONN.TERMINAL 7P BASE POST
CN302 KN2506297 CONN.TERMINAL 6P BASE POST
CN501 KZ042260L CONN.TERMINAL 26P CONNECTOR
CN503 KN2502091 CONN.TERMINAL 2P BASE POST
CN504 KN2502091 CONN.TERMINAL 2P BASE POST
CN701 KZ041160L CONN.TERMINAL 16P FPC CONNE
CN702 KZ040060L CONN.TERMINAL 6P FPC CONNE
CN704 KN530409L CONN.TERMINAL 4P BASE POST
CN771 KX0040800 CONN.TERMINAL 8P BUS CONNE
CN901 KX0071600 CONN.TERMINAL DC CONNE
(
16P
)
C1 CY473623J C.CAPACITOR 0.047 MF
C10 CE1071468 E.CAPACITOR 100MF /10V
C102 CZ5616D2J C.CAPACITOR
C103 CE1056468 E.CAPACITOR 1MF /50V
C106 CY273623J C.CAPACITOR 0.027 MF
C11 CZ3316D2J C.CAPACITOR 330 PF
C112 CE1056468 E.CAPACITOR 1MF /50V
C116 CY222623J C.CAPACITOR 0.0022MF
C118 CY472623J C.CAPACITOR 0.0047MF
C119 CE1063468 E.CAPACITOR 10MF /16V
C120 CZ4716D2J C.CAPACITOR 470 PF
C141 CE1056468 E.CAPACITOR 1MF /50V
C142 CE1056468 E.CAPACITOR 1MF /50V
C143 CZ3316D2J C.CAPACITOR 330 PF
C144 CZ3316D2J C.CAPACITOR
C151 CE4754468 E.CAPACITOR 4.7MF /25V
C152 CY122623J C.CAPACITOR
C153 CZ1216D2J C.CAPACITOR 120 PF
C154 CZ1016D2J C.CAPACITOR
C155 CE4760468 E.CAPACITOR 47MF /6.3V
C156 CE1071468 E.CAPACITOR 100MF /10V
C161 CE1056468 E.CAPACITOR 1MF /50V
C162 CE2263468 E.CAPACITOR 22MF /16V
C163 CY473623J C.CAPACITOR 0.047 MF
C164 CY224122J C.CAPACITOR
C172 CE1063468 E.CAPACITOR 10MF /16V
C173 CE2260468 E.CAPACITOR 22MF /6.3V
C174 CY223623J C.CAPACITOR 0.022 MF
C175 CE4760468 E.CAPACITOR 47MF /6.3V
C2 CE1046468 E.CAPACITOR 0.1MF /50V
C202 CZ5616D2J C.CAPACITOR
C203 CE1056468 E.CAPACITOR 1MF /50V
C206 CY273623J C.CAPACITOR 0.027 MF
C21 CE2271468 E.CAPACITOR 220MF /10V
C212 CE1056468 E.CAPACITOR 1MF /50V
C216 CY222623J C.CAPACITOR 0.0022MF
C218 CY472623J C.CAPACITOR
C219 CE1063468 E.CAPACITOR 10MF /16V
C22 CE2263468 E.CAPACITOR 22MF /16V
C220 CZ4716D2J C.CAPACITOR
C23 CY473623J C.CAPACITOR 0.047 MF
C241 CE1056468 E.CAPACITOR 1MF /50V
C242 CE1056468 E.CAPACITOR 1MF /50V
C243 CZ3316D2J C.CAPACITOR
C244 CZ3316D2J C.CAPACITOR 330 PF
C25 CY473623J C.CAPACITOR 0.047 MF
C251 CE4754468 E.CAPACITOR 4.7MF /25V
C252 CY122623J C.CAPACITOR
C253 CZ1216D2J C.CAPACITOR 120 PF
C254 CZ1016D2J C.CAPACITOR
C26 CE1063468 E.CAPACITOR 10MF /16V
C27 CZ7R06B2J C.CAPACITOR 7 PF
C272 CE1063468 E.CAPACITOR 10MF /16V
C273 CE2260468 E.CAPACITOR 22MF /6.3V
C28 CZ6R06B2J C.CAPACITOR 6 PF
C29 CZ2R06A0J C.CAPACITOR 2 PF
C3 CY102623J C.CAPACITOR 0.001MF
C30 CY473623J C.CAPACITOR 0.047 MF
C301 CE4754468 E.CAPACITOR 4.7MF /25V
C302 CE4754468 E.CAPACITOR 4.7MF /25V
C303 CE4763468 E.CAPACITOR 47MF /16V
C305 CE4754468 E.CAPACITOR 4.7MF /25V
C306 CE4754468 E.CAPACITOR 4.7MF /25V
C307 CE1071468 E.CAPACITOR 100MF /10V
C308 CE4754468 E.CAPACITOR 4.7MF /25V
C309 CE4754468 E.CAPACITOR 4.7MF /25V
C31 CY103623J C.CAPACITOR
C310 CE1071468 E.CAPACITOR 100MF /10V
C32 CY103623J C.CAPACITOR 0.01 MF
C321 CE1063468 E.CAPACITOR 10MF /16V
C322 CY103623J C.CAPACITOR 0.01 MF
C323 CE4763468 E.CAPACITOR 47MF /16V
C324 CE1063468 E.CAPACITOR 10MF /16V
C325 CE2256468 E.CAPACITOR 2.2MF /50V
C326 CY682623J C.CAPACITOR 0.0068MF
C327 CY823423J C.CAPACITOR 0.082 MF
C329 CE2256468 E.CAPACITOR 2.2MF /50V
C33 CY103623J C.CAPACITOR 0.01 MF
C330 CY123623J C.CAPACITOR
C331 CY562623J C.CAPACITOR 0.0056MF
C332 CY273623J C.CAPACITOR
C333 CY273623J C.CAPACITOR
C334 CY333623J C.CAPACITOR
C335 CE2256468 E.CAPACITOR 2.2MF /50V
C336 CY473623J C.CAPACITOR 0.047 MF
C337 CY473623J C.CAPACITOR 0.047 MF
C34 CY333623J C.CAPACITOR
C35 CY473623J C.CAPACITOR
C351 CY104423J C.CAPACITOR 0.1 MF
C352 CY103623J C.CAPACITOR 0.01 MF
C353 CE4754468 E.CAPACITOR 4.7MF /25V
C354 CY104423J C.CAPACITOR 0.1 MF
C355 CZ4716D2J C.CAPACITOR
C356 CE1063468 E.CAPACITOR 10MF /16V
C357 CY472623J C.CAPACITOR 0.0047MF
C358 CY224122J C.CAPACITOR
C359 CY224122J C.CAPACITOR 0.22 MF
C36 CY103623J C.CAPACITOR
C37 CY272623J C.CAPACITOR
C38 CY102623J C.CAPACITOR 0.001MF
C39 CY102623J C.CAPACITOR 0.001MF
C4 CE2271468 E.CAPACITOR 220MF /10V
C401 CE4754468 E.CAPACITOR 4.7MF /25V
C402 CE4754468 E.CAPACITOR 4.7MF /25V
C403 CE4763468 E.CAPACITOR 47MF /16V
C405 CE4754468 E.CAPACITOR 4.7MF /25V
C406 CE4754468 E.CAPACITOR 4.7MF /25V
C407 CE1071468 E.CAPACITOR 100MF /10V
C408 CE4754468 E.CAPACITOR 4.7MF /25V
C409 CE4754468 E.CAPACITOR 4.7MF /25V
C410 CE1071468 E.CAPACITOR 100MF /10V
C451 CY104423J C.CAPACITOR
C452 CY103623J C.CAPACITOR
C454 CY104423J C.CAPACITOR 0.1 MF
C455 CZ4716D2J C.CAPACITOR 470 PF
560 PF
560 PF
0.01 MF
0.0027 MF
