16
Speaker output settings
Select the output setting for the speakers [ SPK/PRE OUT], base on the
speaker connection method.
Connection via lineout terminals
For connections through an external amplifier. (  25 )
(For KD-R670 )
Setting on
[ SPK/PRE OUT]
Audio signal through lineout terminal
FRONT REAR/SW
REAR/REAR Front speakers output Rear speakers output
REAR/SUB.W Front speakers output Subwoofer output
SUB.W/SUB.W Front speakers output Subwoofer output
(For
KD-R570 / KD-R470 / KD-R370 )
Setting on
[ SPK/PRE OUT]
Audio signal through lineout terminal
REAR/SW
REAR/REAR Rear speakers output
REAR/SUB.W Subwoofer output
SUB.W/SUB.W Subwoofer output
Connection via speaker leads
For connections without using an external amplifier. However, with this
settings you can also enjoy the subwoofer output. (
 25 )
(For KD-R670 / KD-R570 / KD-R470 / KD-R370 )
Setting on
[ SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
REAR/REAR Rear speakers output Rear speakers output
REAR/SUB.W Rear speakers output Rear speakers output
SUB.W/SUB.W Subwoofer output (Mute)
If [ SUB.W/SUB.W ] is selected:
– [
HIGH120HZ ] is selected in [ SUB.W  LPF ] and [ THROUGH ] is not available.
– [
R01 ] is selected in [ FADER ] and selectable range is [ R06 ]to [ 00 ]
AUDIO SETTINGS
For KD-R775S
HPF
OFF :All signals are sent to the front/rear speakers.; LOW  100HZ /
MID  120HZ / HIGH150HZ :Audio signals with frequencies lower than
100Hz/ 120Hz/ 150Hz are cut off from the front/rear speakers.
FADER R06 — F06 ( 00 ):Adjusts the front and rear speaker output balance.
BALANCE
*
4
L06 — R06 ( 00 ):Adjusts the left and right speaker output balance.
VOL ADJUST –15 — +06 ( 00 ):Preset the initial volume level of each source
(compared to the FM volume level). Before adjustment, select the
source you want to adjust. (“VOLADJFIX” appears if FM is selected.)
AMP GAIN LOW  POWER :Limits the maximum volume level to 25. (Select if the
maximum power of each speaker is less than 50W to prevent damaging
the speakers.);
HIGHPOWER :The maximum volume level is 35.
D.T.EXP
(Digital Track
Expander)
ON :Creates realistic sound by compensating the high-frequency
components and restoring the rise-time of the waveform that are lost in
audio data compression.;
OFF :Cancels.
TEL  MUTING
*
5
ON :Mutes the sounds while using the cellular phone (not connected
through KS-BTA100).;
OFF :Cancels.
For
KD-R670 / KD-R570 / KD-R470 / KD-R370
SPK/PRE
 OUT Depending on the speaker connection method, select the appropriate
setting to get the desired output. (
 Speaker output settings )
*
4
This adjustment will not affect the subwoofer output.
*
5
Does not work if [ BT  ADAPTER ] is selected for [ AUX ] in [ SRC  SELECT ]. (  4 )
JS_JVC_KD_R775S_K_EN_7.indd 16 27/7/2015 3:21:56 PM
