AUDIO SETTINGS
Crossover settings
Below are the available setting items for 2-way crossover and 3-way
crossover.
Caution
Select a crossover type according to how the speakers are connected.
(
35
)
If you select a wrong type:
• The speakers may damage.
• The output sound level may be extremely high or low.
SPEAKER SIZE
Selects according to the connected speaker size for optimum
performance.
•
The frequency and slope settings are automatically set for the crossover
of the selected speaker.
•
If [
NONE
] is selected for [
TWEETER
] of [
FRONT
], [
REAR
] and [
SUBWOOFER
]
for [
SPEAKER SIZE
], the [
X ‘ OVER
] setting of the selected speaker is not
available.
X ‘ OVER
(crossover)
•
[
FRQ
]/[
F-HPF FRQ
]/[
R-HPF FRQ
]/[
SW LPF FRQ
]/[
HPF FRQ
]/[
LPF FRQ
]: Adjusts the
crossover frequency for the selected speakers (high pass filter or low
pass filter).
If [
THROUGH
] is selected, all signals are sent to the selected speakers.
•
[
SLOPE
]/[
F-HPF SLOPE
]/[
R-HPF SLOPE
]/[
SW LPF SLOPE
]/[
HPF SLOPE
]/[
LPF SLOPE
]
:
Adjusts the crossover slope.
Selectable only if a setting other than [
THROUGH
] is selected for the
crossover frequency.
•
[
SW LPF PHASE
]/
[PHASE]:
Selects the phase of the speaker output to be in
line with the other speaker output.
• [
GAIN LEFT
]/[
GAIN RIGHT
]/[
F-HPF GAIN
]/[
R-HPF GAIN
]/[
SW LPF GAIN
]/[
GAIN
]:
Adjusts the output volume of the selected speaker.
Speaker output settings
[SPK/PRE OUT]
(Applicable only if [X ' OVER TYPE ] is set to [2-WAY])
(
23
)
Select the output setting for the speakers [
SPK/PRE OUT],
based on the
speaker connection method.
Connection via lineout terminals
For connections through an external amplifier. (
35
)
Setting on
[
SPK/PRE OUT]
Audio signal through lineout terminal
FRONT REAR/SW
REAR/REAR
Front speakers output Rear speakers output
REAR/SUB.W
(default) Front speakers output Subwoofer output
SUB.W/SUB.W
Front speakers output Subwoofer output
Connection via speaker leads
For connections without using an external amplifier. However, with this
settings you can also enjoy the subwoofer output. (
35
)
Setting on
[
SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
REAR/REAR
Rear speakers output Rear speakers output
REAR/SUB.W
Rear speakers output Rear speakers output
SUB.W/SUB.W
Subwoofer output (Mute)
If [
SUB.W/SUB.W
] is selected:
– [
FRQ 120HZ
] is selected in [
SUB.W
LPF
] and [
THROUGH
] is not available.
– [
POSITION R02
] is selected in [
FADER
] and selectable range is [
POSITION
R15
]to [
POSITION 00
].
