ENGLISH
20
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUDIO SETTINGS
BALANCE
*
4
POSITION L15
to
POSITION R15
(
POSITION 00
):Adjusts the left and
right speaker output balance.
VOLUME
ADJUST LEVEL –15
to
LEVEL +06
(
LEVEL 00
):Preset the initial volume level
of each source (compared to the FM volume level). Before adjustment,
select the source you want to adjust.
AMP
GAIN LOW
POWER
:Limits the maximum volume level to 25. (Select if
the maximum power of each speaker is less than 50W to prevent
damaging the speakers.);
HIGH POWER
:The maximum volume
level is 35.
SPK/PRE
OUT
(Not applicable when 3-way crossover is selected.)
Depending on the speaker connection method, select the appropriate
setting to get the desired output.
( 21, Speaker output settings)
SPEAKER SIZE
Depending on the crossover type you have selected (
[X ' OVER
TYPE]
), 2-way crossover or 3-way crossover setting items will be
shown.
( 22, Crossover settings)
By default, 2-way crossover type is selected.
X ' OVER
DTA SETTINGS
For settings,
23, Digital Time Alignment settings
.
CAR SETTINGS
X ' OVER TYPE Caution
: Adjust the volume before changing the
[X ' OVER TYPE]
to
avoid the sudden increase or decrease of the output level.
2-WAY
(Displayed only when
[3-WAY]
is selected.)
YES
:Selects two way crossover type.;
NO
:Cancels.
3-WAY
(Displayed only when
[2-WAY]
is selected.)
YES
:Selects three way crossover type.;
NO
:Cancels.
*
1
Displayed only when
[SUBWOOFER SET]
is set to
[ON]
.
*
2
For 2-way crossover: Displayed only when
[SPK/PRE OUT]
is set to
[SUB.W/SUB.W]
.
( 21)
*
3
For 2-way crossover: Displayed only when
[SPK/PRE OUT]
is set to
[REAR/SUB.W]
or
[SUB.W/SUB.W]
.
( 21)
*
4
This adjustment will not affect the subwoofer output.
PRO EQ
Adjust your own sound settings.
•
The settings are stored to
[USER]
.
•
The settings made may affect the current settings of
[EASY EQ]
.
62.5HZ
LEVEL –09
to
LEVEL +09 (LEVEL 00)
: Adjusts the level to memorize for each source.
(Before making an adjustment, select the source you want to adjust.)
ON
:Turns on the extended bass.;
OFF
:Cancels.
100HZ
/
160HZ
/
250HZ
/
400HZ
/
630HZ
/
1KHZ
/
1.6KHZ
/
2.5KHZ
/
4KHZ
/
6.3KHZ
/
10KHZ
/
16kHZ
LEVEL –09
to
LEVEL +09 (LEVEL 00)
:
Adjusts the level to memorize for each source.
(Before making an adjustment, select the source you want to adjust.)
Q FACTOR 1.35
/
1.50
/
2.00
:Adjust the quality factor.
AUDIO CONTROL
BASS BOOST
LEVEL +01
to
LEVEL +05
: Selects your preferred bass boost level.;
OFF
:Cancels.
LOUDNESS LEVEL 01
/
LEVEL 02
:Boosts low or high frequencies to produce a
well-balanced sound at low volume.;
OFF
:Cancels
SUB.W LEVEL
*
1
SPK-OUT
*
2
(Not applicable when 3-way crossover is selected.)
SUB.W 00
to
SUB.W +06
(
SUB.W +03
):Adjusts
the output level of the subwoofer connected via
speaker lead.
( 32)
PRE-OUT
*
3
SUB.W –50
to
SUB.W +10
(
SUB.W 00
):Adjusts
the output level of the subwoofer connected to
the lineout terminals (SW or REAR/SW) through an
external amplifier.
( 32)
SUBWOOFER SET
*
3
ON
: Turns on the subwoofer output.;
OFF
: Cancels.
FADER
(Not applicable when 3-way crossover is selected.)
POSITION R15
to
POSITION F15
(
POSITION 00
):Adjusts the front
and rear speaker output balance.
JS_JVC_KD_R981_E_EN_5.indd 20JS_JVC_KD_R981_E_EN_5.indd 20 9/1/2016 2:06:57 PM9/1/2016 2:06:57 PM
