JVC KD-S550 Service Manual

Item
Parts number
Parts name
Area
A
Parts list (General assembly)
Q'ty
Description
Block No.
M1MM
1
ZCKDS600J-NPA
NOSE PIECE
1
1-1 1-2 S600J
ZCKDS550J-NPA
NOSE PIECE
1
1-1 1-2 S550E/J
1-1
FSJC1057-001
FRONT PANEL
1
1-2
FSJD3023-00A
FINDER ASSY
1
KD-S600 J
FSJD3023-00B
FINDER LENS
1
KD-S550 E/J
2
FSJC1029-021
TOP CHASSIS
1
3
FSMH3001-002
HEAT SINK
1
KD-S550 J
FSMH3001-202
SIDE PANEL
1
KD-S600J/S550E
4
FSKM3011-002
BOTTOM COVER
1
5
FSMA3004-003
INSULATOR
1
6
QYSDST2604Z
SCREW
3
CHASSIS+MECHA B
7
FSKZ4005-001
SCREW
3
8
QYSDST2606Z
SCREW
3
CHASSIS+REAR BK
9
QYSDST2606Z
SCREW
2
CHASSIS+MAIN PW
11
FSJC2013-002
FRONT CHASSIS
1
12
FSKS3010-001
LOCK LEVER
1
13
FSKW4005-003
TORSION SPRING
1
FOR LOCK LEVEL
14
FSXP3026-002
RLS KNOB
1
15
FSKW3002-015
COMP.SPRING
1
16
FSPK3009-001
BLIND
1
17
---------------
CD MECHA
1
TN-CCD1001Z
21
FSXP2035-038
PRESET BUTTON
1
KD-S550 J
FSXP2035-058
PRESET BUTTON
1
KD-S600J/S550E
22
FSXP3053-002
POWER BUTTON
1
23
FSXP3054-002
EJECT BUTTON
1
KD-S600J/S550E
FSXP3054-001
EJECT BUTTON
1
KD-S550 J
24
FSXP4005-019
OPERAT.BUTTON
1
25
FSXP3068-001
PUSH BUTTON
1
26
FSXP2034-034
OPERAT BUTTON
1
CD/FM/AM
27
FSXP2044-001
OPERAT.BUTTON
1
30
FSXP3055-001
DETACH BUTTON
1
31
FSKW3002-012
COMP. SPRING
1
FOR DETACH BUTT
32
FSJK3026-001
CD LENS
1
33
FSJC1043-002
REAR COVER
1
34
VKZ4777-001
MINI SCREW
4
FRONT+REAR
35
FSYN3105-D006
NAME PLATE
1
KD-S600 J
FSYN3104-D005
NAME PLATE
1
KD-S550 E
FSYN3104-006
NAME PLATE
1
KD-S550 J
40
QMFZ021-100-J1
FUSE
1
41
VMA4652-001SS
EARTH PLATE
1
42
QLD0126-001
LCD MODULE
1
KD-S550 E
QLD0103-001
LCD MODULE
1
KD-S600J/S550J
43
FSYH3023-001
LCD CASE
1
44
FSJK3035-001
LCD LENS
1
45
FSKS3022-001
LENS CASE
1
46
QNZ0442-001
RUBBER CONNE
1
51
FSKM3010-013
REAR BRACKET
1
52
FSKL4018-00B
IC BRACKET
1
53
FSKL4015-002
REG BRACKET
1
54
QYSDST2606Z
SCREW
1
FOR ANT
55
QYSDST2606Z
SCREW
3
16P & TR BRACK
56
QYSDSF3006Z
SCREW
1
LINE OUT
57
FSKL4014-001
HEAT SINK
1
58
FSYH4078-001
LIGHT SHEET
1
A
