KD-S570/KD-S620
1-23
8
7
6
5
4
3
2
1
V
+
B OUTPUT
B INPUT
B INPUT
A INPUT
A INPUT
A OUTPUT
-
V
-
+
+
-
NJM4565M-WE (IC151) : Ope. amp
