JVC KD-S621 Service Manual

KD-S621
3-3
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
1 ------------
CD MECHA
1
TN-CCD1001Z
2 FSJC1029-404
TOP CHASSIS
1
3 FSMH3001-202
SIDE PANEL
1
4 FSKM3011-002
BOTTOM COVER
1
5 FSMA3004-203
INSULATOR
1
6 QYSDST2604Z
SCREW
3
CHASSIS+MECHA BKT
7 FSKZ4005-001
SCREW
2
CHASSIS+SIDE PANEL
8 QYSDST2604Z
SCREW
3
CHASSIS+REAR BKT
9 QYSDST2606Z
SCREW
2
CHASSIS+MAIN PWB
10 FSKZ4005-001
SCREW
1
SIDE PANEL+IC BKT
11 FSJC2013-013
FRONT CHASSIS
1
12 FSKS3010-001
LOCK LEVER
1
13 FSKW4005-003
TORSION SPRING
1
FOR LOCK LEVEL
14 FSXP3026-002
RLS KNOB
1
15 FSKW3002-015
COMP.SPRING
1
16 FSPK3009-002
BLIND
1
17 GE10037-001A
FRONT PANEL
1
18 GE30300-008A
FINDER ASSY
1
19 GE20119-001A
PRESET BUTTON
1
20 GE30304-001A
POWER BUTTON
1
21 GE30305-001A
EJECT BUTTON
1
22 GE20131-001A
D FUNC BUTTON
1
FM/CD/AM
23 GE30307-001A
SND FTN BUTTON
1
24 GE20130-001A
PUSH BUTTON
1
25 GE20118-001A
+/- BUTTON
1
26 GE20120-001A
UP/DOWN BUTTON
1
27 GE30306-001A
DETACH BUTTON
1
28 FSKW3002-012
COMP. SPRING
1
FOR DETACH BUTTON
29 GE30117-001A
LIGHT LENS
1
30 GE10038-001A
REAR COVER
1
31 VKZ4777-001
MINI SCREW
4
FRONT+REAR
32 QLD0210-002
LCD
1
33 GE30302-002A
LCD CASE
1
34 FSJK3035-001
LCD LENS
1
35 FSKS3022-003
LENS CASE
1
36 FSYH4078-002
LIGHTING SHEET
1
38 QNZ0442-001
RUBBER CONNE
1
39 GE30348-002A
NAME PLATE
1
40 QMFZ047-150-T
FUSE
A
1
41 VMA4652-001SS
EARTH PLATE
1
42 FSKM3010-020
REAR BRACKET
1
43 FSKL4024-001
IC BRACKET
1
44 GE40104-001B
HEAT SINK
1
45 GE40103-001A
REGULATOR BKT
1
46 QYSDST2606Z
SCREW
1
FOR ANT
47 QYSDSF3006Z
SCREW
1
LINE OUT
48 QYSDST2606Z
SCREW
3
16P & TR BRACK
