KD-S641
(No.49769)1-7
2.1.8 Removing the front board
(See Figs.10 to 12)
• Prior to performing the following procedure, remove the front
panel assembly.
(1) Remove the four screws J on the back side of the front pan-
el assembly.
(2) Release the eleven joints f.
(3) Take out the front board.
Fig.10
Fig.11
Fig.12
J
J
J
Joint f
Joint f
Rear cover
Front panel
Joint f
Joint f
Joint
f
Front board
