JVC KD-S680 Service Manual

KD-S680
3-3
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
1 ------------
CD MECHA (1325)
1
2 FSJC1029-401
TOP CHASSIS
1
3 FSMH3001-202
HEAT SINK
1
4 FSKM3011-002
BOTTOM COVER
1
5 FSMA3004-203
INSULATOR
1
6 QYSDST2604Z
SCREW
3
CHASSIS+MECHA BKT
7 FSKZ4005-001
SCREW
2
CHASSIS+SIDE PANEL
8 QYSDST2604Z
SCREW
3
CHASSIS+REAR BKT
9 QYSDST2606Z
SCREW
2
CHASSIS+MAIN PWB
10 FSKZ4005-001
SCREW
1
SIDE PANEL+IC BKT
11 FSJC2013-013
FRONT CHASSIS
1
12 FSKS3010-001
LOCK LEVER
1
13 FSKW4005-003
TORSION SPRING
1
FOR LOCK LEVEL
14 FSXP3026-002
RLS KNOB
1
15 FSKW3002-015
COMP.SPRING
1
16 FSPK3009-002
BLIND
1
17 GE10003-001A
FRONT PANEL
1
18 GE30111-013A
FINDER ASSY
1
19 GE20104-002A
PRESET BUTTON
1
20 GE30105-002B
POWER BUTTON
1
21 GE30109-002A
EJECT BUTTON
1
22 GE20110-004C
D.FUNCT BUTTON
1
FM/CD/AM
23 GE30112-001A
PUSH BUTTON(2)
1
24 GE40102-001A
REMOTE LENS
1
25 GE30366-001A
SEL BUTTON
1
26 FSYH4036-032
SHEET
1
FOR SEL BUTTON
27 GE30546-001A
KNOB
1
28 GE30104-001A
RIM LENS
1
29 GE20109-001C
UP DOWN BUTTON
1
30 GE30106-001A
SND FUNC BUTTON
1
31 FSXP3055-001
DETACH BUTTON
1
32 FSKW3002-012
COMP. SPRING
1
FOR DETACH BUTTON
33 GE30117-001A
LIGHT LENS
1
34 GE10004-001B
REAR COVER
1
35 VKZ4777-001
MINI SCREW
4
FRONT+REAR
36 QLD0216-001
LCD MODULE
1
37 QNZ0442-001
RUBBER CONNE
1
38 GE30276-001A
LCD CASE
1
39 FSJK3025-001
LCD LENS
1
40 FSKS3019-001
LENS CASE
1
41 FSYH4074-001
LIGHTING SHEET
1
42 GE30322-002A
NAME PLATE
1
43 QMFZ047-150-T
FUSE
A
1
44 VMA4652-001SS
EARTH PLATE
1
45 FSKM3010-020
REAR BRACKET
1
46 FSKL4024-001
IC BRACKET
1
47 GE40104-002B
HEAT SINK
1
48 GE40103-001A
REG BRACKET
1
