JVC KD-S743R Service Manual

KD-S743R/KD-S741R
3-3
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
1 ---------------------
CD MECHA
1
2 GE10043-205A
TOP CHASSIS
1
3 GE40135-001A
EARTH PLATE
1
4 GE30568-006A
HEAT SINK
1
5 GE30393-002A
BOTTOM COVER
1
6 FSMA3004-203
INSULATOR
1
7 QYSDST2604Z
SCREW
3
CHASSIS+CD MECH
8 FSKZ4005-001
SCREW
2
CHASSIS+SIDE PA
9 QYSDST2604Z
SCREW
3
CHASSIS+REAR BK
10 QYSDST2606Z
SCREW
2
CHASSIS+MAIN PW
11 QYSDST2612Z
SCREW
2
SIDE PANEL+IC B
12 GE10056-002A
FRONT CHASSIS
1
KD-S743
GE10056-001A
FRONT CHASSIS
1
KD-S741
13 GE30583-001A
LOCK LEVER
1
14 FSKW4005-003
TORSION SPRING
1
FOR LOCK LEVEL
15 FSXP3026-002
RLS KNOB
1
16 FSKW3002-015
COMP.SPRING
1
17 GE40140-001A
BLIND
1
18 QYSDST2004M
SCREW
2
19 GE10037-003A
FRONT PANEL
1
KD-S743
GE10037-001A
FRONT PANEL
1
KD-S741
20 GE30300-018A
FINDER ASSY
1
KD-S741
GE30300-024A
FINDER ASSY
1
KD-S743
21 GE20119-001A
PRESET BUTTON
1
22 GE30304-001A
POWER BUTTON
1
23 GE30305-001A
EJECT BUTTON
1
24 GE20131-002A
D.FUNC BUTTON
1
FM/CD/AM
25 GE30307-001A
SUD FUNC BUTTON
1
26 GE20130-012A
PUSH BUTTON
1
27 GE20118-002A
+/- BUTTON
1
28 GE20120-001A
UP/DOWN BUTTON
1
29 GE30306-001A
DETACH BUTTON
1
30 FSKW3002-012
COMP. SPRING
1
FOR DETACH BUTT
31 GE30117-001A
LIGHT LENS
1
32 GE10055-001A
REAR COVER
1
KD-S741
GE10055-002A
REAR COVER
1
KD-S743
33 VKZ4777-001
MINI SCREW
4
FRONT+REAR
34 GE30302-001A
L.C.D.CAS
1
35 FSJK3025-001
LCD LENS
1
36 GE30301-001A
LENS CASE
1
37 GE40142-005A
LIGHTING SHEET
1
38 FSYH4071-002
LIGHTING SHEET
1
39 GE30669-001A
NAME PLATE
1
KD-S743
GE30666-001A
NAME PLATE
1
KD-S741
40 E70891-001
CLASS 1 LABEL
1
41 LV41843-001A
LASER CAUTION
A
1
42 QLD0265-001
LCD MODULE
1
