KD-S743R/KD-S741R
3-4
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
43 QNZ0442-001
LCD CONNECTOR
1
44 GE30382-018A
REAR BRACKET
1
GE30382-001A
REAR BRACKET
EX
1
KD-S743
45 QYSDST2606Z
SCREW
1
REAR BKT+REG BK
46 QYSDST2606Z
SCREW
1
REAR BKT+ANT JA
47 QYSDST2606Z
SCREW
1
REAR BKT+CD IN
QYSDSF2606Z
SCREW
EX
1
KD-S741,KD-S743
48 QYSDSF2606Z
SCREW
1
REAR BKT+PIN JA
49 QMFZ047-150-T
FUSE
A
1
50 GE40124-001A
REG BRACKET
1
51 GE40136-001A
IC BRACKET
1
53 FSYH4070-005
LIGHTING SHEET
1
52 GE30854-001A
LED HOLDER
1
