JVC KD-S777R

Item
Parts number
Parts name
Area
A
Electrical parts list ( Main board )
Remarks
Block No. 01
C 706
QEKJ0JM-107Z
E CAPACITOR
100MF 20% 6.3V
C 707
NCB21HK-103X
C CAPACITOR
C 708
QERF0JM-107Z
E CAPACITOR
100MF 20% 6.3V
C 709
NCB21HK-103X
C CAPACITOR
C 712
NCS21HJ-680X
C CAPACITOR
C 713
NCB21HK-103X
C CAPACITOR
C 718
NCB21HK-103X
C CAPACITOR
C 719
NCB21EK-104X
C CAPACITOR
C 720
NCB21EK-104X
C CAPACITOR
C 721
NCB21EK-104X
C CAPACITOR
C 781
QEKJ0JM-107Z
E CAPACITOR
100MF 20% 6.3V
C 782
QERF1CM-226Z
E CAPACITOR
22MF 20% 16V
C 783
NCB21EK-823X
C CAPACITOR
C 801
NCB21HK-103X
C CAPACITOR
KD-SX878R
C 802
NCB21EK-473X
C CAPACITOR
KD-SX878R
C 891
NCB21EK-473X
C CAPACITOR
C 901
QER41AM-227
E CAPACITOR
220MF 20% 10V
C 902
NCB21HK-103X
C CAPACITOR
C 903
QEKJ1CM-226Z
E CAPACITOR
22MF 20% 16V
C 904
QER41AM-227
E CAPACITOR
220MF 20% 10V
C 905
QER41CM-106
E CAPACITOR
10MF 20% 16V
C 906
QER41CM-106
E CAPACITOR
10MF 20% 16V
C 907
QERF1HM-225Z
E CAPACITOR
2.2MF 20% 50V
C 908
QEZ0338-228
E CAPACITOR
2200MF
C 909
NCB21EK-104X
C CAPACITOR
C 911
QERF1AM-476Z
E CAPACITOR
47MF 20% 10V
C 912
QER41AM-107
E CAPACITOR
100MF 20% 10V
C 913
QEKJ1CM-107Z
E CAPACITOR
100MF 20% 16V
C 914
QERF1EM-475Z
E CAPACITOR
4.7MF 20% 25V
C 915
QER41CM-106
E CAPACITOR
10MF 20% 16V
CN501
QGB2027M1-26S
CONNECTOR
CP601
VMC0334-001
CONNECTOR
F.PANEL CONN.
CP961
QNZ0112-001
CAR CONNECTOR
D 1
1SS133-T1
SI DIODE I/M
D 2
1SS133-T1
SI DIODE I/M
D 3
MA152WK-X
SI DIODE
D 161
MA152WK-X
SI DIODE
D 241
1SS133-T1
SI DIODE I/M
D 242
1SS133-T1
SI DIODE I/M
D 341
MA152WA-X
DIODE
D 501
DSK10C-T1
DIODE
D 502
DSK10C-T1
DIODE
D 701
MA3056/M/-X
ZENER DIODE
D 702
MA3056/M/-X
ZENER DIODE
D 703
MA3056/M/-X
ZENER DIODE
D 704
MA3056/M/-X
ZENER DIODE
D 705
MA3056/M/-X
ZENER DIODE
D 706
MA3056/M/-X
ZENER DIODE
D 781
MA152WK-X
SI DIODE
D 782
1SS133-T1
SI DIODE I/M
D 784
MA3110/M/-X
ZENER DIODE
D 891
MA152WA-X
DIODE
D 909
MA152WA-X
DIODE
D 910
CRS03-W
SB DIODE
D 911
1N5401-TU-15
DIODE
D 912
CRS03-W
SB DIODE
D 953
MA152WK-X
SI DIODE
IC 71
SAA6579T-X
IC
IC161
TEA6320T-X
IC
IC301
HA13158A
IC
IC501
LA6557-X
IC
IC521
TA2109F-X
IC
IC541
TC9462F
IC
Item
Parts number
Parts name
Area
A
Remarks
IC581
NJM4565M-WE
IC
IC701
UPD178078GF-524
IC
KD-SX878R
IC801
HD74HC126FP-X
IC
KD-SX878R
IC961
BA4905-V3
IC
J 1
QNZ0009-001
CAR ANT JACK
J 301
QNN0170-001
PIN JACK (REEL)
J 801
QNZ0095-001
CONNECTOR
KD-SX878R
L 1
QQL244J-4R7Z
INDUCTOR
L 541
QQL244J-4R7Z
INDUCTOR
L 542
QQL244J-4R7Z
INDUCTOR
L 701
QQL244J-4R7Z
INDUCTOR
L 961
QQR0703-001
CHOKE COIL
Q 1
UN2211-X
TRANSISTOR
Q 2
2SD601A/R/-X
TRANSISTOR
Q 3
UN2111-X
TRANSISTOR
Q 4
2SB709A/R/-X
TRANSISTOR
Q 5
2SB815/7/-X
TRANSISTOR
Q 7
UN2211-X
TRANSISTOR
Q 31
2SD601A/R/-X
TRANSISTOR
Q 32
2SD601A/R/-X
TRANSISTOR
Q 41
2SD601A/R/-X
TRANSISTOR
Q 42
2SC3661-X
TRANSISTOR
Q 43
UN2211-X
TRANSISTOR
Q 51
2SD601A/R/-X
TRANSISTOR
Q 52
2SD601A/R/-X
TRANSISTOR
Q 53
UN2211-X
TRANSISTOR
Q 161
2SD601A/R/-X
TRANSISTOR
Q 162
UN2111-X
TRANSISTOR
Q 174
UN2111-X
TRANSISTOR
Q 181
2SD601A/R/-X
TRANSISTOR
Q 241
2SD601A/R/-X
TRANSISTOR
Q 341
2SD1048/6-7/-X
TRANSISTOR
Q 351
2SD1048/6-7/-X
TRANSISTOR
Q 501
2SB1322/RS/-T
TRANSISTOR
Q 521
2SB1322/RS/-T
TRANSISTOR
Q 781
UN2111-X
TRANSISTOR
Q 782
UN2211-X
TRANSISTOR
Q 783
UN2111-X
TRANSISTOR
Q 891
UN2211-X
TRANSISTOR
Q 901
2SB709A/R/-X
TRANSISTOR
Q 902
UN2213-X
TRANSISTOR
Q 976
UN2211-X
TRANSISTOR
Q 977
2SB709A/R/-X
TRANSISTOR
R 1
NRSA02J-0R0X
MG RESISTOR
R 2
NRSA02J-102X
MG RESISTOR
R 3
NRSA02J-102X
MG RESISTOR
R 4
NRSA02J-223X
MG RESISTOR
R 5
NRSA02J-472X
MG RESISTOR
R 6
NRSA02J-473X
MG RESISTOR
R 7
NRSA02J-472X
MG RESISTOR
R 8
NRSA02J-473X
MG RESISTOR
R 9
NRSA02J-332X
MG RESISTOR
R 10
NRS181J-8R2X
MG RESISTOR
R 31
NRSA02J-102X
MG RESISTOR
R 32
NRSA02J-103X
MG RESISTOR
R 33
NRSA02J-152X
MG RESISTOR
R 41
NRSA02J-332X
MG RESISTOR
R 42
NRSA02J-102X
MG RESISTOR
R 43
NRSA02J-102X
MG RESISTOR
R 44
NRS181J-330X
MG RESISTOR
R 51
NRSA02J-471X
MG RESISTOR
R 52
NRSA02J-153X
MG RESISTOR
R 53
NRSA02J-103X
MG RESISTOR
IC701
UPD178078GF-522
IC(MICRO-COMP)
KD-S777R
