JVC KD-S777R

Item
Parts number
Parts name
Area
A
Electrical parts list ( Front board )
Remarks
Block No. 02
C 672
NBE20JM-475X
TS E CAPACITOR
C 681
NCB21HK-223X
C CAPACITOR
C 682
NCB21HK-223X
C CAPACITOR
C 691
NCB21HK-223X
C CAPACITOR
C 697
NBE41DM-225X
TS E CAPACITOR
C 698
NCS21HJ-681X
C CAPACITOR
CP691
VMC0335-001
CONNECTOR
D 631
SML-310LT/MN/-X
LED
POWER LED
D 632
LNJ308G81/1-3/X
LED
R.ENC LED1
D 633
LNJ308G81/1-3/X
LED
R.ENC LED2
D 634
LNJ308G81/1-3/X
LED
R.ENC LED3
D 635
LNJ308G81/1-3/X
LED
R.ENC LED4
D 636
LNJ308G81/1-3/X
LED
R.ENC LED5
D 637
LNJ308G81/1-3/X
LED
SEL LED1
D 638
LNJ308G81/1-3/X
LED
SEL LED2
D 639
LNJ308G81/1-3/X
LED
SEL LED3
D 640
LNJ308G81/1-3/X
LED
EJECT LED
D 641
LNJ308G81/1-3/X
LED
F.SKIP/UP LED
D 642
LNJ308G81/1-3/X
LED
B.SKIP/DOWN LED
D 643
LNJ308G81/1-3/X
LED
MO/RND LED
D 644
LNJ308G81/1-3/X
LED
RPT LED
D 645
LNJ308G81/1-3/X
LED
CD LED
D 646
LNJ308G81/1-3/X
LED
FM/AM LED
D 647
LNJ308G81/1-3/X
LED
EXT/CD-CH LED
D 648
LNJ308G81/1-3/X
LED
1 LED
D 649
LNJ308G81/1-3/X
LED
2 LED
D 650
LNJ308G81/1-3/X
LED
3 LED
D 651
LNJ308G81/1-3/X
LED
4 LED
D 652
LNJ308G81/1-3/X
LED
5 LED
D 653
LNJ308G81/1-3/X
LED
6 LED
D 654
LNJ308G81/1-3/X
LED
SOUND
D 655
LNJ308G81/1-3/X
LED
DISPLAY
D 656
LNJ308G81/1-3/X
LED
SCAN
D 657
LNJ308G81/1-3/X
LED
BBE LED
D 659
NSPW310BS/BRS/
LED
LCD ILLUM.LED1
D 660
NSPW310BS/BRS/
LED
LCD ILLUM.LED2
D 670
MA3051/M/-X
ZENER DIODE
D 671
MA3056/M/-X
ZENER DIODE
D 691
MA3051/M/-X
ZENER DIODE
D 692
MA152WK-X
SI DIODE
IC680
RPM6938-SV4
IC
IC691
LC75823W
IC
JS690
QSW0863-001
JOG SHUTTLE SW
R 602
NRSA02J-821X
MG RESISTOR
R 603
NRSA02J-821X
MG RESISTOR
R 604
NRSA02J-122X
MG RESISTOR
R 605
NRSA02J-182X
MG RESISTOR
R 606
NRSA02J-272X
MG RESISTOR
R 608
NRSA02J-821X
MG RESISTOR
R 609
NRSA02J-821X
MG RESISTOR
R 610
NRSA02J-122X
MG RESISTOR
R 611
NRSA02J-182X
MG RESISTOR
R 612
NRSA02J-272X
MG RESISTOR
R 613
NRSA02J-392X
MG RESISTOR
R 614
NRSA02J-103X
MG RESISTOR
R 616
NRSA02J-821X
MG RESISTOR
R 617
NRSA02J-821X
MG RESISTOR
R 618
NRSA02J-122X
MG RESISTOR
R 619
NRSA02J-182X
MG RESISTOR
R 620
NRSA02J-272X
MG RESISTOR
R 631
NRSA02J-271X
MG RESISTOR
R 632
NRSA02J-271X
MG RESISTOR
R 633
NRSA02J-271X
MG RESISTOR
R 634
NRSA02J-271X
MG RESISTOR
R 635
NRSA02J-271X
MG RESISTOR
R 636
NRSA02J-271X
MG RESISTOR
R 637
NRSA02J-271X
MG RESISTOR
R 638
NRSA02J-271X
MG RESISTOR
R 639
NRSA02J-511X
MG RESISTOR
R 640
NRSA02J-511X
MG RESISTOR
R 641
NRSA02J-511X
MG RESISTOR
R 642
NRSA02J-511X
MG RESISTOR
R 643
NRSA02J-511X
MG RESISTOR
R 644
NRSA02J-511X
MG RESISTOR
R 645
NRSA02J-681X
MG RESISTOR
R 646
NRSA02J-681X
MG RESISTOR
R 647
NRSA02J-681X
MG RESISTOR
R 648
NRSA02J-681X
MG RESISTOR
R 649
NRSA02J-681X
MG RESISTOR
R 650
NRSA02J-681X
MG RESISTOR
R 651
NRSA02J-561X
MG RESISTOR
R 652
NRSA02J-152X
MG RESISTOR
R 671
NRSA02J-103X
MG RESISTOR
R 672
NRSA02J-471X
MG RESISTOR
R 681
NRSA02J-101X
MG RESISTOR
R 690
NRSA02J-221X
MG RESISTOR
R 691
NRSA02J-222X
MG RESISTOR
R 692
NRSA02J-222X
MG RESISTOR
R 693
NRSA02J-103X
MG RESISTOR
R 694
NRSA02J-103X
MG RESISTOR
R 695
NRSA02J-103X
MG RESISTOR
R 696
NRSA02J-103X
MG RESISTOR
R 697
NRSA02J-684X
MG RESISTOR
R 698
NRSA02J-154X
MG RESISTOR
S 601
NSW0124-001X
TACT SWITCH
POWER
S 602
NSW0124-001X
TACT SWITCH
SOUND
S 603
NSW0124-001X
TACT SWITCH
DISPLAY
S 604
NSW0124-001X
TACT SWITCH
SCAN
S 605
NSW0124-001X
TACT SWITCH
BBE
S 606
NSW0124-001X
TACT SWITCH
1 /VCR FUNC.
S 607
NSW0124-001X
TACT SWITCH
SELECT
S 608
NSW0124-001X
TACT SWITCH
2
S 609
NSW0124-001X
TACT SWITCH
3 /VCR PLAY
S 610
NSW0124-001X
TACT SWITCH
4 /VCR STOP
S 611
NSW0124-001X
TACT SWITCH
5 /VCR REW
S 612
NSW0124-001X
TACT SWITCH
6 /VCR FWD
S 613
NSW0124-001X
TACT SWITCH
F.SKIP/UP
S 614
NSW0124-001X
TACT SWITCH
EJECT
S 615
NSW0124-001X
TACT SWITCH
EXT./CD-CH
S 616
NSW0124-001X
TACT SWITCH
FM/AM
S 617
NSW0124-001X
TACT SWITCH
CD
S 618
NSW0124-001X
TACT SWITCH
RPT
S 619
NSW0124-001X
TACT SWITCH
MO/RND
S 620
NSW0124-001X
TACT SWITCH
B.SKIP/DOWN
Item
Parts number
Parts name
Area
A
Remarks
