3-17
Switch board
Block No. [0][2]
R9626 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9634 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R9635 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9636 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R9637 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R9638 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R9639 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R9641 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9642 NRSA63J-563X MG RESISTOR 56k
Ω
1/16W J
R9651 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9652 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R9654 NRVA63B-562X CMF RESISTOR 5.6k
Ω
1/16W B
R9655 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9656 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9657 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9659 NRSA63J-155X MG RESISTOR 1.5M
Ω
1/16W J
R9660 NRVA63B-562X CMF RESISTOR 5.6k
Ω
1/16W B
R9661 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R9662 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9663 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J
R9664 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9665 NRVA63B-223X CMF RESISTOR 22k
Ω
1/16W B
R9666 NRVA63B-223X CMF RESISTOR 22k
Ω
1/16W B
R9667 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9668 NRVA63B-472X CMF RESISTOR 4.7k
Ω
1/16W B
R9669 NRVA63B-472X CMF RESISTOR 4.7k
Ω
1/16W B
R9670 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R9673 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
R9674 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R9675 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R9676 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9678 NRS181J-120X MG RESISTOR 12
Ω
1/8W J
R9681 NRS016J-100X MG RESISTOR 10
Ω
1W J
R9683 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R9684 NRS181J-120X MG RESISTOR 12
Ω
1/8W J
R9685 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9686 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R9687 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R9688 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R9689 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R9691 NRS016J-100X MG RESISTOR 10
Ω
1W J
R9693 NRS181J-120X MG RESISTOR 12
Ω
1/8W J
R9694 NRS181J-120X MG RESISTOR 12
Ω
1/8W J
R9701 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9702 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9707 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9708 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9751 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9752 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9757 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9758 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
L1 NQL79GM-4R7X COIL 4.7uH M
L30 NQR0129-003X FERRITE BEADS
L31 NQL093K-2R2X COIL 2.2uH K
L40 NQR0129-003X FERRITE BEADS
L61 NQR0129-003X FERRITE BEADS
L63 NQL093K-1R8X COIL 1.8uH K
L201 NQL382M-470X COIL 47uH M
L202 NQL382M-470X COIL 47uH M
L301 NQL382M-470X COIL 47uH M
L302 NQL382M-100X COIL 10uH M
L701 NQL79GM-100X COIL 10uH M
L706 NQL79GM-4R7X COIL 4.7uH M
L901 NQL114K-100X COIL 10uH K
L951 QQR1660-001 CHOKE COIL
L952 QQR1660-001 CHOKE COIL
L955 QQR1660-001 CHOKE COIL
L956 QQR1660-001 CHOKE COIL
L961 QQR1660-001 CHOKE COIL
L962 QQR1660-001 CHOKE COIL
L965 QQR1660-001 CHOKE COIL
L966 QQR1660-001 CHOKE COIL
L5001 QQR1669-001 CHOKE COIL
L7201 NQL79GM-470X COIL 47uH M
L9071 NQL56CK-220X NDUCTOR 22uH K
BZ720 QAN0023-001Z BUZZER
Symbol No.
Part No. Part Name Description Local
CN345 QGA2501C1-07 CONNECTOR W-B (1-7)
CN351 QNZ0095-001 CONNECTOR
CN381 QGA2501C1-06 CONNECTOR W-B (1-6)
CN701 QGF1041C1-16W CONNECTOR FFC/FPC (1-16)
CN720 QGA2006C1-02 CONNECTOR W-B (1-2)
CN721 QGB2027M5-20S CONNECTOR B-B (1-20)
CN901 QNZ0090-001 CAR CONNECTOR
CN911 QGA2501C1-02 CONNECTOR W-B (1-2)
CN912 QGA2001C1-04 CONNECTOR W-B (1-4)
J1 QAM0556-001 ANT CABLE
K5001 QQR0678-001Z FERRITE BEADS
K5002 QQR0678-001Z FERRITE BEADS
K5003 QQR0678-001Z FERRITE BEADS
K7200 NQR0022-005X FERRITE BEADS
K7201 NQR0022-005X FERRITE BEADS
PP1 QZW0010-001 STYLE PIN
PP2 QZW0010-001 STYLE PIN
TH901 NAD0036-224X N THERMISTOR 220k
Ω
TH902 NAD0031-002X N THERMISTOR
Ω
TU1 QAU0325-004 TUNER PACK
W501 QAM0741-001 CAR CABLE
W951 QAM0740-001 CAR CABLE
X1 NAX0749-001X CRYSTAL
X342 NAX0664-001X CRYSTAL
X701 NAX0552-001X RESONATOR
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
IC461 GP1UX511RK RM.RECEIVER
IC471 K4S161622H-UC60 IC
IC471 or MSM56V16160F8T3 IC
IC491 SG32M90TFIR31E IC(PROGRAMED)
IC801 MN103S77NEB IC
IC881 IC-PST3424U-X IC
Q430 UN2211-X TRANSISTOR
Q431 UN2211-X TRANSISTOR
Q440 2SB709A/QR/-X TRANSISTOR
Q441 2SB709A/QR/-X TRANSISTOR
Q442 2SB709A/QR/-X TRANSISTOR
Q471 UN2211-X TRANSISTOR
Q472 UN211L-X TRANSISTOR
Q880 2SD601A/QR/-X TRANSISTOR
Q881 2SD601A/QR/-X TRANSISTOR
D401 MA8062/M/-X Z DIODE
D402 MA8062/M/-X Z DIODE
D403 MA8062/M/-X Z DIODE
D404 MA8062/M/-X Z DIODE
D405 MA8062/M/-X Z DIODE
D406 MA8062/M/-X Z DIODE
D407 MA8062/M/-X Z DIODE
D408 MA8062/M/-X Z DIODE
D409 MA8062/M/-X Z DIODE
D410 NECBB205/WQR/-X LED
D411 NECBB205/WQR/-X LED
D412 NECBB205/WQR/-X LED
D413 NECBB205/WQR/-X LED
D414 NECBB205/WQR/-X LED
D415 NECBB205/WQR/-X LED
D416 NECBB205/WQR/-X LED
D417 MA8056/M/-X Z DIODE
D420 S30AW0A03/5B3-X LED
D421 S30AW0A03/5B3-X LED
D422 S30AW0A03/5B3-X LED
D430 SML-310LT/MN/-X LED
D431 SML-310LT/MN/-X LED
D441 MA152WK-X SI DIODE
D474 MA111-X SI DIODE
D478 MA111-X SI DIODE
