3-19
Mechanism control board
Block No. [0][3]
X801 NAX0663-001X C RESONATOR
Symbol No.
Part No. Part Name Description Local
IC430 SN74AHCU04PW-X IC
IC502 BR24L01AFV-W-X IC
IC503 SN74AHCT126PW-X IC(DIGITAL)
IC504 NJU7241F33-X IC
IC601 TC94A15FG IC
IC651 NJU7772F15-X IC
IC652 TC94A34FG-002 IC
IC653 MSM51V17405F5TS IC
IC654 SN74CBTLV3257PX IC
IC655 SN74AHC1G08V-X IC
IC681 LA6242H-X IC
Q430 2SB624/4/-X TRANSISTOR
Q431 UN2211-X TRANSISTOR
Q501 UN211M-X DIGI TRANSISTOR
Q502 UN2211-X TRANSISTOR
Q503 RPM-22PB
TRANSISTOR
Q504 UN2211-X TRANSISTOR
Q601 2SB1132/QR/-W TRANSISTOR
Q651 UN2211-X TRANSISTOR
Q652 2SB624/4/-X TRANSISTOR
Q681 2SB1184/QR/-X TRANSISTOR
D506 1SS355-X SI DIODE
D682 1SR154-400-X DIODE
C431 NDC31HJ-270X C CAPACITOR 27pF 50V J
C432 NDC31HJ-270X C CAPACITOR 27pF 50V J
C433 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C501 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C502 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C503 NEAG0GM-227X E CAPACITOR 220uF 4V M
C504 NDC31HJ-220X C CAPACITOR 22pF 50V J
C505 NDC31HJ-220X C CAPACITOR 22pF 50V J
C506 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C507 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C508 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C509 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C510 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C511 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C512 NEAG0GM-227X E CAPACITOR 220uF 4V M
C513 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C514 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C516 NEAG0GM-227X E CAPACITOR 220uF 4V M
C530 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C551 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C597 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C598 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C599 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C601 NEAF0JM-107X E CAPACITOR 100uF 6.3V M
C602 NCB31HK-681X C CAPACITOR 680pF 50V K
C603 NEAF0JM-107X E CAPACITOR 100uF 6.3V M
C604 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C605 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C606 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C607 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C608 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C610 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C612 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C613 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C614 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C615 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C616 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C617 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C618 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C621 NCB31CK-104X C CAPACITOR 0.1uF 16V K
Symbol No.
Part No. Part Name Description Local
C622 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C623 NCS31HJ-470X C CAPACITOR 47pF 50V J
C624 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C625 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C626 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C627 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C629 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C630 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C631 NCS31HJ-471X C CAPACITOR 470pF 50V J
C632 NCS31HJ-471X C CAPACITOR 470pF 50V J
C633 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C634 NCB31HK-472X C CAPACITOR 4700pF 50V K
C635 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C636 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C637 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C638 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C640 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C641 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C642 NCS31HJ-101X C CAPACITOR 100pF 50V J
C643 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C644 NCB31AK-334X C CAPACITOR 0.33uF 10V K
C645 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C646 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C647 NCS31HJ-680X C CAPACITOR 68pF 50V J
C648 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C649 NCB31HK-562X C CAPACITOR 5600pF 50V K
C651 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C652 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C653 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C654 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C655 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C656 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C658 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C659 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C660 NCS31HJ-101X C CAPACITOR 100pF 50V J
C661 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C662 NCS31HJ-101X C CAPACITOR 100pF 50V J
C663 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C664 NCB31HK-222X C CAPACITOR 2200pF 50V K
C665 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C666 NCS31HJ-101X C CAPACITOR 100pF 50V J
C668 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C669 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C670 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C671 NBE21AM-106X TA E CAPACITOR 10uF 10V M
C672 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C674 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C675 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C677 NDC31HJ-471X C CAPACITOR 470pF 50V J
C678 NDC31HJ-471X C CAPACITOR 470pF 50V J
C680 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C682 NEAF1EM-475X E CAPACITOR 4.7uF 25V M
C683 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C684 NEAF1CM-476X E CAPACITOR 47uF 16V M
C685 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C686 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C687 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C688 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C689 NEAF1CM-476X E CAPACITOR 47uF 16V M
C690 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C693 NEAF1CM-476X E CAPACITOR 47uF 16V M
C907 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C908 NCB31CK-104X C CAPACITOR 0.1uF 16V K
R431 NRSA63J-225X MG RESISTOR 2.2M
Ω
1/16W J
R432 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R434 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R437 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R438 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R439 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R440 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R441 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R501 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R502 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R503 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R504 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R505 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R506 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
