Crossover settings
Below are the available setting items for 2-way crossover and 3-way
crossover.
CAUTION
Select a crossover type according to how the speakers are connected.
(Page 42, 43)
If you select a wrong type:
• The speakers may be damaged.
• The output sound level may be extremely high or low.
SPEAKER SIZE
Selects according to the connected speaker size for optimum performance.
• The frequency and slope settings are automatically set for the crossover of
the selected speaker.
• If
[NONE] is selected for the following speaker in [SPEAKER SIZE] , the [X ‘ OVER]
setting of the selected speaker is not available.
– 2-way crossover:
[TWEETER] of [FRONT] / [REAR] / [SUBWOOFER]
– 3-way crossover: [WOOFER]
X ‘ OVER (crossover)
•
[FRQ] / [F-HPFFRQ] / [R-HPFFRQ] / [SWLPF FRQ] / [HPFFRQ] / [LPFFRQ] : Adjusts the
crossover frequency for the selected speakers (high pass filter or low pass
filter).
If
[THROUGH] is selected, all signals are sent to the selected speakers.
•
[SLOPE] / [F-HPFSLOPE] / [R-HPFSLOPE] / [SWLPF SLOPE] / [HPFSLOPE] / [LPFSLOPE] :
Adjusts the crossover slope.
Selectable only if a setting other than
[THROUGH] is selected for the
crossover frequency.
•
[SW LPF PHASE] / [PHASE] : Selects the phase of the speaker output to be in line
with the other speaker output.
•
[GAINLEFT] / [GAINRIGHT] / [F-HPFGAIN] / [R-HPFGAIN] / [SWLPF GAIN] / [GAIN] : Adjusts
the output volume of the selected speaker.
Audio Settings
Connection via speaker leads
You can also connect the speakers without using an external amplifier
but still being able to enjoy the subwoofer output with these settings.
(Page 42, 43)
Setting on
[SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
[REAR/REAR] Rear speakers output Rear speakers output
[REAR/SUB.W]* Rear speakers output Rear speakers output
[SUB.W/SUB.W] Subwoofer output (Mute)
If [SUB.W/SUB.W] is selected:
–
[120HZ] is selected in [SUBWOOFERLPF] and [THROUGH] is not available.
(Page 29)
–
[POSITION R02] is selected in [FADER] and selectable range is [POSITION R15] to
[POSITION 00] . (Page 26)
* Except for KD-T922BT/KD-X38MDBT.
