ENGLISH
45
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Specifications
Audio
Band 13 Band
Frequency 62.5/ 100 /160 /250 /400 /630 /1k /1.6 k /2.5k
/4k /6.3k/ 10k/ 16k Hz
Level -09 — +09 (-9dB — +9dB)
Q 1.35/ 1.5/ 2.0
HPF Frequency Through/ 30/ 40/ 50/ 60/ 70/ 80/ 90/ 100/ 120/
150/ 180/ 220/ 250 Hz
Level -6/ -12/ -18/ -24 dB/Oct
Q -8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 dB
LPF Frequency Through/ 30/ 40/ 50/ 60/ 70/ 80/ 90/ 100/ 120/
150/ 180/ 220/ 250 Hz
Level -6/ -12/ -18/ -24 dB/Oct
Q -8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 dB
Preout Level/Load 2 500 mV/10 kΩ
Preout Impedance ≤ 600 Ω
General
Operating Voltage 12 V DC car battery
Installation Size (W × H × D) KD-T922BT/KD-DB622BT:
182 mm × 53 mm × 156 mm
KD-X38MDBT: 182 mm × 53 mm × 100 mm
Net Weight (includes Trimplate,
Mounting Sleeve)
KD-DB622BT: 1.3 kg
KD-T922BT: 1.2 kg
KD-X38MDBT: 0.6 kg
Subject to change without notice.
USB
Dynamic Range 93 dB
Channel Separation KD-T922BT/KD-DB622BT: 90 dB
KD-X38MDBT: 89 dB
MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
WMA Decode Compliant with Windows Media Audio
AAC Decode KD-T922BT: AAC-LC “.aac”, “.m4a” files
WAV Decode Linear-PCM
FLAC Decode FLAC file, up to 24 bit/96 kHz
Auxiliary
Frequency Response (±3 dB) 20 Hz — 20 kHz
Input Maximum Voltage 1 000 mV
Input Impedance 30 kΩ
Bluetooth
Version Bluetooth V4.2
Frequency Range 2.402 GHz — 2.480 GHz
RF Output Power (E.I.R.P.) +4 dBm (MAX), Power Class 2
Maximum Communication Range Line of sight approx. 10 m (32.8 ft)
Pairing SSP (Secure Simple Pairing)
Profile HFP1.7.1 (Hands-Free Profile)
A2DP (Advanced Audio Distribution Profile)
AVRCP1.6.1 (Audio/Video Remote Control Profile)
PBAP (Phonebook Access Profile)
SPP (Serial Port Profile)
Audio
Maximum Output Power 50 W × 4 or
50 W × 2 + 50 W × 1 (Subwoofer = 4 Ω)
Full Bandwidth Power
(at less than 1 % THD)
22 W × 4
Speaker Impedance 4 Ω — 8 Ω
JS_JVC_KD_T922BT_E_EN_2.indd 45JS_JVC_KD_T922BT_E_EN_2.indd 45 4/2/2020 3:18:56 PM4/2/2020 3:18:56 PM
