ﺍﺪﺻ ﺕﺎﻤﻴﻈﻨﺗ
VOLUME ADJUST ﻊﺒﻨﻣ ﺮﻫ یﺍﺪﺻ ﻪﻴﻟﻭﺍ ﺢﻄﺳ :( LEVEL 00 ) LEVEL +06 ﺎﺗ LEVEL –15
ﻊﺒﻨﻣ ،ﻢﻴﻈﻨﺗ ﺯﺍ ﻞﺒﻗ .ﺪﻨﻛ ﯽﻣ ﻢﻴﻈﻨﺗ ﺶﻴﭘ ﺯﺍ ﺍﺭ (FM ﻡﻮﻟﻭ ﺢﻄﺳ ﺎﺑ ﻪﺴﻳﺎﻘﻣ ﺭﺩ)
ﻪﻨﻳﺰﮔ ،FM ﺏﺎﺨﺘﻧﺍ ﺕﺭﻮﺻ ﺭﺩ) .ﺪﻴﻳﺎﻤﻧ ﺏﺎﺨﺘﻧﺍ ﺍﺭ ﺪﻴﻨﻛ ﻢﻴﻈﻨﺗ ﺪﻴﻫﺍﻮﺧ ﯽﻣ ﻪﻛ
(.ﺩﻮﺷ ﯽﻣ ﺮﻫﺎﻇ “VOL ADJ FIX”
AMP GAIN ﺮﺜﻛﺍﺪﺣ ﺮﮔﺍ) .ﺪﻨﻛ ﯽﻣ ﺩﻭﺪﺤﻣ 25 ﻪﺑ ﺍﺭ ﺍﺪﺻ ﻡﻮﻟﻭ ﻥﺍﺰﻴﻣ ﺮﺜﻛﺍﺪﺣ : LOW POWER
ﻥﺪﻳﺩ ﺐﻴﺳﺁ ﺯﺍ یﺮﻴﮔﻮﻠﺟ یﺍﺮﺑ ،ﺖﺳﺍ ﺕﺍﻭ 50 ﺯﺍ ﺮﺘﻤﻛ ﺎﻫﻮﮔﺪﻨﻠﺑ ﺯﺍ ﮏﻳ ﺮﻫ ﻥﺍﻮﺗ
ﻡﻮﻟﻭ ﻥﺍﺰﻴﻣ ﺮﺜﻛﺍﺪﺣ :
HIGH POWER ؛ (.ﺪﻴﻨﻛ ﺏﺎﺨﺘﻧﺍ ﺍﺭ ﻪﻨﻳﺰﮔ ﻦﻳﺍ ﺎﻫﻮﮔﺪﻨﻠﺑ
.ﺖﺳﺍ 35 ﺍﺪﺻ
D.T.EXPANDER
ﻩﺪﻨﻫﺩ ﺵﺮﺘﺴﮔ)
(ﻝﺎﺘﻴﺠﻳﺩ ﯽﺑﺎﻳﺩﺭ
ﻪﻛ ﻞﻜﺷ ﯽﺟﻮﻣ ﻡﺮﻓ ﺝﻭﺍ ﻥﺎﻣﺯ ﯽﺑﺎﻳﺯﺎﺑ ﻭ ﻻﺎﺑ ﺲﻧﺎﻛﺮﻓ یﺎﻫ ﻪﻔﻟﺆﻣ ﻥﺍﺮﺒﺟ ﺎﺑ : ON
ﯽﻣ ﺩﺎﺠﻳﺍ ﺍﺭ ﯽﻌﻗﺍﻭ ﯽﻳﺎﻫﺍﺪﺻ ،ﺪﻧﺍ ﻪﺘﻓﺭ ﻦﻴﺑ ﺯﺍ ﺍﺪﺻ یﺎﻫ ﻩﺩﺍﺩ یﺯﺎﺳ ﻩﺩﺮﺸﻓ ﺭﺩ
.ﺩﻮﺷ ﻰﻣ ﻮﻐﻟ :
OFF ؛ .ﺪﻨﻛ
SPK/PRE OUT
ﯽﺟﻭﺮﺧ ﺎﺗ ﺪﻴﻫﺩ ﻡﺎﺠﻧﺍ ﺍﺭ ﺐﺳﺎﻨﻣ ﺕﺎﻤﻴﻈﻨﺗ ،ﺎﻫﻮﮔﺪﻨﻠﺑ ﻝﺎﺼﺗﺍ ﻉﻮﻧ ﻪﺑ ﻪﺘﺴﺑ
(ﺎﻫﻮﮔﺪﻨﻠﺑ ﯽﺟﻭﺮﺧ ﺕﺎﻤﻴﻈﻨﺗ
) .ﺪﻴﻨﻛ ﺖﻓﺎﻳﺭﺩ ﯽﺑﻮﻠﻄﻣ
ﺎﻫﻮﮔﺪﻨﻠﺑ ﯽﺟﻭﺮﺧ ﺕﺎﻤﻴﻈﻨﺗ
.ﺪﻴﻨﻛ ﺏﺎﺨﺘﻧﺍ ، [SPK/PRE OUT] ﺎﻫﻮﮔﺪﻨﻠﺑ یﺍﺮﺑ ﺍﺭ ﯽﺟﻭﺮﺧ ﺕﺎﻤﻴﻈﻨﺗ ،ﺎﻫﻮﮔﺪﻨﻠﺑ ﻝﺎﺼﺗﺍ ﻉﻮﻧ ﻪﺑ ﻪﺟﻮﺗ ﺎﺑ
ﯽﺟﻭﺮﺧ یﺎﻫ ﻪﻧﺎﻳﺎﭘ ﻖﻳﺮﻃ ﺯﺍ ﻝﺎﺼﺗﺍ
(19 ) .ﺪﺷﺎﺑ ﯽﻣ ﯽﺟﺭﺎﺧ ﺮﻳﺎﻓ ﯽﻠﭙﻣﺁ ﻖﻳﺮﻃ ﺯﺍ ﻪﻛ ﯽﺗﻻﺎﺼﺗﺍ یﺍﺮﺑ
KD-X252
یﺯﺎﺳ ﻝﺎﻌﻓ
[SPK/PRE OUT]
(lineout) ﯽﺟﻭﺮﺧ ﻦﻳﻻ ﻪﻧﺎﻳﺎﭘ ﻖﻳﺮﻃ ﺯﺍ ﯽﺗﻮﺻ ﻝﺎﻨﮕﻴﺳ
FRONTREAR/SW
REAR/REAR
ﻮﻠﺟ یﺎﻫﻮﮔﺪﻨﻠﺑ ﯽﺟﻭﺮﺧﺐﻘﻋ یﺎﻫﻮﮔﺪﻨﻠﺑ ﯽﺟﻭﺮﺧ
REAR/SUB.W
(ﺽﺮﻓ ﺶﻴﭘ)
ﻮﻠﺟ یﺎﻫﻮﮔﺪﻨﻠﺑ ﯽﺟﻭﺮﺧﺮﻓﻭﻭ ﺏﺎﺳ ﯽﺟﻭﺮﺧ
SUB.W/SUB.W
ﻮﻠﺟ یﺎﻫﻮﮔﺪﻨﻠﺑ ﯽﺟﻭﺮﺧﺮﻓﻭﻭ ﺏﺎﺳ ﯽﺟﻭﺮﺧ
KD-X152
یﺯﺎﺳ ﻝﺎﻌﻓ
[SPK/PRE OUT]
(lineout) ﯽﺟﻭﺮﺧ ﻦﻳﻻ ﻪﻧﺎﻳﺎﭘ ﻖﻳﺮﻃ ﺯﺍ ﯽﺗﻮﺻ ﻝﺎﻨﮕﻴﺳ
REAR/SW
REAR/REAR
ﺐﻘﻋ یﺎﻫﻮﮔﺪﻨﻠﺑ ﯽﺟﻭﺮﺧ
(ﺽﺮﻓ ﺶﻴﭘ)
REAR/SUB.W
ﺮﻓﻭﻭ ﺏﺎﺳ ﯽﺟﻭﺮﺧ
SUB.W/SUB.W
ﺮﻓﻭﻭ ﺏﺎﺳ ﯽﺟﻭﺮﺧ
ﻮﮔﺪﻨﻠﺑ یﺎﻫ ﻢﻴﺳ ﻖﻳﺮﻃ ﺯﺍ ﻝﺎﺼﺗﺍ
ﺪﻴﻧﺍﻮﺗ ﯽﻣ ﺰﻴﻧ ﺕﺎﻤﻴﻈﻨﺗ ﻦﻳﺍ ﺎﺑ ،ﻝﺎﺣ ﻦﻳﺍ ﺎﺑ .ﺪﺷﺎﺑ ﯽﻣ ﯽﺟﺭﺎﺧ ﺮﻳﺎﻓ ﯽﻠﭙﻣﺁ ﺯﺍ ﻩﺩﺎﻔﺘﺳﺍ ﻥﻭﺪﺑ ﻪﻛ ﯽﺗﻻﺎﺼﺗﺍ یﺍﺮﺑ
(19 ) .ﺪﻳﺮﺒﺑ ﺕﺬﻟ ﺮﻓﻭﻭ ﺏﺎﺳ ﯽﺟﻭﺮﺧ ﺯﺍ
یﺯﺎﺳ ﻝﺎﻌﻓ
[SPK/PRE OUT]
ﺐﻘﻋ یﻮﮔﺪﻨﻠﺑ ﻢﻴﺳ ﻖﻳﺮﻃ ﺯﺍ ﯽﺗﻮﺻ ﻝﺎﻨﮕﻴﺳ
(ﭗﭼ) L(ﺖﺳﺍﺭ) R
REAR/REAR
ﺐﻘﻋ یﺎﻫﻮﮔﺪﻨﻠﺑ ﯽﺟﻭﺮﺧﺐﻘﻋ یﺎﻫﻮﮔﺪﻨﻠﺑ ﯽﺟﻭﺮﺧ
REAR/SUB.W
ﺐﻘﻋ یﺎﻫﻮﮔﺪﻨﻠﺑ ﯽﺟﻭﺮﺧﺐﻘﻋ یﺎﻫﻮﮔﺪﻨﻠﺑ ﯽﺟﻭﺮﺧ
SUB.W/SUB.W
ﺮﻓﻭﻭ ﺏﺎﺳ ﯽﺟﻭﺮﺧ(ﺍﺪﺻ ﻊﻄﻗ)
:ﺪﺷﺎﺑ ﻩﺪﺷ ﺏﺎﺨﺘﻧﺍ
[SUB.W/SUB.W] ﺮﮔﺍ
.ﺖﺴﻴﻧ ﺮﻳﺬﭘ ﻥﺎﻜﻣﺍ
[FRQ THROUGH] ﻭ ﺩﻮﺷ ﯽﻣ ﺏﺎﺨﺘﻧﺍ [SUBWOOFER LPF] ﺭﺩ [FRQ 120HZ] –
(11 )
ﺎﺗ [POSITION R06] ﻦﻴﺑ ﺏﺎﺨﺘﻧﺍ ﻞﺑﺎﻗ ﻩﺯﺎﺑ ﻭ ﺩﻮﺷ ﯽﻣ ﺏﺎﺨﺘﻧﺍ [FADER] ﺭﺩ [POSITION R01] –
(11 ) .ﺪﺷﺎﺑ ﯽﻣ [POSITION 00]
