JVC KD-X262 Quick Start Guide

6
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
RADIO
Search for a station
1 Press B SRC repeatedly to select FM or AM.
2 Press S / T to search for a station automatically.
(or)
Press and hold S / T until “M” flashes, then press repeatedly to
search for a station manually.
Settings in memory
You can store up to 18 stations for FM and 6 stations for AM.
Store a station
While listening to a station....
Press and hold one of the number buttons (1 to 6).
(or)
1 Press and hold the volume knob until “PRESETMODE” flashes.
2 Turn the volume knob to select a preset number, then press the knob.
“MEMORY” appears once the station is stored.
Select a stored station
Press one of the number buttons (1to6).
(or)
1 Press .
2 Turn the volume knob to select a preset number, then press the knob.
USB/iPod/ANDROID
Selectable source:
• KD-X262: USB/iPod/ANDROID
• KD-X162: USB/ANDROID
Start playback
The source changes automatically and playback starts when you attach a
device (USB device/ iPod/iPhone/ Android device) to the USB input terminal.
To On the faceplate
Reverse/Fast-forward
Press and hold S / T.
Select a file
Press S / T.
Select a folder
Press 2 J / 1 K.
Repeat play
Press 4  repeatedly.
Random play
Press 3  repeatedly.
JS_JVC_QSG_KD_X262_E_EN_int1.indd 6JS_JVC_QSG_KD_X262_E_EN_int1.indd 6 6/14/2018 3:13:08 PM6/14/2018 3:13:08 PM

JVC KD-X262 Specifications

General

DIN size	-
Output power	200 W
Product color	Black, Red
Ready for iPod	Yes
High pass filter	No
Audio output channels	- channels
Equalizer bands quantity	3
Maximum power per channel	50 W
Audio formats supported	FLAC, MP3, WAV, WMA
USB version	2.0
USB port position	Front
USB connector type	USB Type-A
USB ports quantity	1
AM band range	531 - 1611 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	AM, FM, LW, MW
Preset stations quantity	24
Display type	LCD
Illumination color	White
Package weight	900 g

Weight and Dimensions

Depth	100 mm
Width	182 mm
Height	53 mm
Weight	600 g
