JVC KD-X262 Quick Start Guide

8
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
OTHER INFORMATION
For playback operations of AUX source, refer to the INSTRUCTION MANUAL
on the following website: <http://www.jvc.net/cs/car/>
• The availability of each source vary depending on the model.
Note for specifications
Speaker Impedance:
4 Ω — 8 Ω
Operating Voltage:
12 V DC car battery
8 Press to exit the setting menu.
Note:
You need to set [SPK/PRE OUT] to [REAR/SUB.W] or [SUB.W/SUB.W] before you can
make the subwoofer level settings.
JS_JVC_QSG_KD_X262_E_EN_int1.indd 8JS_JVC_QSG_KD_X262_E_EN_int1.indd 8 6/14/2018 2:43:46 PM6/14/2018 2:43:46 PM

JVC KD-X262 Specifications

General

DIN size	-
Output power	200 W
Product color	Black, Red
Ready for iPod	Yes
High pass filter	No
Audio output channels	- channels
Equalizer bands quantity	3
Maximum power per channel	50 W
Audio formats supported	FLAC, MP3, WAV, WMA
USB version	2.0
USB port position	Front
USB connector type	USB Type-A
USB ports quantity	1
AM band range	531 - 1611 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	AM, FM, LW, MW
Preset stations quantity	24
Display type	LCD
Illumination color	White
Package weight	900 g

Weight and Dimensions

Depth	100 mm
Width	182 mm
Height	53 mm
Weight	600 g
