Audio Settings
Speaker output settings [SPK/PRE OUT]
(Applicable only if [X ' OVER TYPE ] is set to [2-WAY]) (page23)
Select the output setting for the speakers [SPK/PRE OUT] , based on the speaker
connection method.
Connection via lineout terminals
For connections through an external amplifier (Page37)
KD-X38MBS:
Setting on
[SPK/PRE OUT]
Audio signal through lineout terminal
FRONT REAR SW
[REAR/REAR] (default) Front speakers
output
Rear speakers output Subwoofer output
[SUB.W/SUB.W] Front speakers
output
L (left): Subwoofer output
R (right): (Mute)
Subwoofer output
KD-XD28BT:
Setting on
[SPK/PRE OUT]
Audio signal through lineout terminal
FRONT REAR/SW
[REAR/REAR] Front speakers output Rear speakers output
[REAR/SUB.W] (default) Front speakers output Subwoofer output
[SUB.W/SUB.W] Front speakers output Subwoofer output
KD-X280BT/KD-SX27BT:
Setting on
[SPK/PRE OUT]
Audio signal through lineout terminal
REAR/SW
[REAR/REAR] Rear speakers output
[REAR/SUB.W] (default) Subwoofer output
[SUB.W/SUB.W] Subwoofer output
Connection via speaker leads
You can also connect the speakers without using an external amplifier
but still being able to enjoy the subwoofer output with these settings.
(Page36)
Setting on
[SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
[REAR/REAR] Rear speakers output Rear speakers output
[REAR/SUB.W]* Rear speakers output Rear speakers output
[SUB.W/SUB.W] Subwoofer output (Mute)
If [SUB.W/SUB.W] is selected:
–
[120HZ] is selected in [SUBWOOFERLPF] and [THROUGH] is not available.
(Page26)
–
[POSITION R02] is selected in [FADER] and selectable range is [POSITION R15] to
[POSITION 00] . (Page23)
* Except for KD-X38MBS.
