Specifications
Audio
Band 13 Band
Frequency 62.5/ 100/ 160/ 250/ 400/ 630/ 1k/ 1.6k/ 2.5k/
4k/ 6.3k/ 10k/ 16k Hz
Level -09 — +09 (-9 dB — +9 dB)
Q 1.35/ 1.5/ 2.0
HPF Frequency THROUGH/ 30/ 40/ 50/ 60/ 70/ 80/ 90/ 100/ 120/
150/ 180/ 220/ 250 Hz
Level -6/ -12/ -18/ -24 dB/Oct.
Q -8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 dB
LPF Frequency 30/ 40/ 50/ 60/ 70/ 80/ 90/ 100/ 120/ 150/ 180/
220/ 250 Hz / THROUGH
Level -6/ -12/ -18/ -24 dB/Oct.
Q -8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 dB
Preout Level/Load KD-X38MBS:
4 000 mV/10 kΩ
KD-X280BT/KD-XD28BT/KD-SX27BT:
2 500 mV/10 kΩ
Preout Impedance ≤ 600 Ω
General
Operating Voltage 12 V DC car battery
Installation Size (W × H × D) 182 mm × 53 mm × 100 mm
(7-3/16" × 2-1/16" × 3-15/16")
Net Weight (includes Trimplate,
Mounting Sleeve)
0.6 kg (1.3 lbs)
Subject to change without notice.
