AUDIO SETTINGS
2-way crossover setting items
SPEAKER SIZE
FRONT SIZE
8CM / 10CM / 12CM / 13CM / 16CM / 17CM / 18CM /
4×6 / 5×7 / 6×8 / 6×9 / 7×10
TWEETER
SMALL / MIDDLE / LARGE / NONE (not connected)
REAR
*
1
8CM / 10CM / 12CM / 13CM / 16CM / 17CM / 18CM / 4×6 / 5×7 / 6×8 /
6×9 / 7×10 / NONE (not connected)
SUBWOOFER
*
2
*
3
16CM / 20CM / 25CM / 30CM / 38CM OVER / NONE (not connected)
X ' OVER
TWEETER FRQ
1KHZ / 1.6KHZ / 2.5KHZ / 4KHZ / 5KHZ / 6.3KHZ /
8KHZ / 10KHZ / 12.5KHZ
GAIN LEFT
–08DB to 00DB
GAIN RIGHT
–08DB to 00DB
FRONT HPF F-HPF FRQ
30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ /
100HZ / 120HZ / 150HZ / 180HZ / 220HZ / 250HZ /
THROUGH
F-HPF SLOPE
–06DB / –12DB / –18DB / –24DB
F-HPF GAIN
–08DB to 00DB
REAR HPF
*
1
R-HPF FRQ 30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ /
100HZ / 120HZ / 150HZ / 180HZ / 220HZ / 250HZ /
THROUGH
R-HPF SLOPE
–06DB / –12DB / –18DB / –24DB
R-HPF GAIN
–08DB to 00DB
SUBWOOFER
LPF
*
2
*
3
SW LPF FRQ 30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ /
100HZ / 120HZ / 150HZ / 180HZ / 220HZ / 250HZ /
THROUGH
SW LPF SLOPE
–06DB / –12DB / –18DB / –24DB
SW LPF PHASE
REVERSE (180°)/ NORMAL (0°)
SW LPF GAIN –08DB to 00DB
3-way crossover setting items
SPEAKER SIZE
TWEETER
SMALL / MIDDLE / LARGE
MID RANGE
8CM / 10CM / 12CM / 13CM / 16CM / 17CM / 18CM / 4×6 / 5×7 / 6×8 / 6×9
WOOFER
*
3
16CM / 20CM / 25CM / 30CM / 38CM OVER / NONE (not connected)
X ' OVER
TWEETER HPF FRQ
1KHZ / 1.6KHZ / 2.5KHZ / 4KHZ / 5KHZ / 6.3KHZ / 8KHZ /
10KHZ / 12.5KHZ
SLOPE
–06DB / –12DB
PHASE
REVERSE (180°)/ NORMAL (0°)
GAIN –08DB to 00DB
MID RANGE HPF FRQ
30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ / 100HZ /
120HZ / 150HZ / 180HZ / 220HZ / 250HZ / THROUGH
HPF SLOPE
–06DB / –12DB
LPF FRQ
1KHZ / 1.6KHZ / 2.5KHZ / 4KHZ / 5KHZ / 6.3KHZ / 8KHZ /
10KHZ / 12.5KHZ / THROUGH
LPF SLOPE
–06DB / –12DB
PHASE
REVERSE (180°)/ NORMAL (0°)
GAIN –08DB to 00DB
WOOFER
*
3
LPF FRQ 30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ / 100HZ /
120HZ / 150HZ / 180HZ / 220HZ / 250HZ / THROUGH
SLOPE
–06DB / –12DB
PHASE
REVERSE (180°)/ NORMAL (0°)
GAIN –08DB to 00DB
*
1
Displayed only when [SPK/PRE OUT] is set to [REAR/REAR] or [REAR/SUB.W] . ( 22)
*
2
Displayed only when [SPK/PRE OUT] is set to [REAR/SUB.W] or [SUB.W/SUB.W] .
( 22)
*
3
Displayed only when [SUBWOOFER SET] is set to [ON] . ( 20)
