JVC LT-26A70BJ Service Manual

(No.YA492)1-19
4.6.1.2 VIDEO SYSTEM SETTING-2
S088 HD WM R DR 0 - 255 6
S089 HD WM G DR 0 - 255 0
S090 HD WM B DR 0 - 255 233
S091 HDMI CL R DR 0 - 255 255
S092 HDMI CL G DR 0 - 255 0
S093 HDMI CL B DR 0 - 255 3
S094 HDMI WM R DR 0 - 255 8
S095 HDMI WM G DR 0 - 255 0
S096 HDMI WM B DR 0 - 255 242
Item No. Item name Variable range Setting value
D001 CVBS NTSC CON 0 - 255 0
D002 CVBS NTSC BRI 0 - 255 0
D003 CVBS NTSC SHA 0 - 255 0
D004 CVBS NTSC COL 0 - 255 0
D005 CVBS NTSC TIN 0 - 255 0
D006 CVBS PAL CON 0 - 255 0
D007 CVBS PAL BRI 0 - 255 0
D008 CVBS PAL SHA 0 - 255 0
D009 CVBS PAL COL 0 - 255 0
D010 CVBS PAL TIN 0 - 255 0
D011 CVBS SECAM CON 0 - 255 0
D012 CVBS SECAM BRI 0 - 255 0
D013
CVBS SECAML SHA 0 - 255 0
D014 CVBS SECAM COL 0 - 255 0
D015 CVBS SECAM TIN 0 - 255 0
D016 TV PAL CON 0 - 255 0
D017 TV PAL BRI 0 - 255 0
D018 TV PAL SHA 0 - 255 0
D019 TV PAL COL 0 - 255 0
D020 TV PAL TIN 0 - 255 0
D031 TV SECAM CON 0 - 255 0
D032 TV SECAM BRI 0 - 255 0
D033 TV SECAM SHA 0 - 255 0
D034 TV SECAM COL 0 - 255 0
D035 TV SECAM TIN 0 - 255 0
D036 5I S CON 0 - 255 0
D037 5I S BRI 0 - 255 0
D038 5I S SHA 0 - 255 0
D039 5I S COL 0 - 255 0
D040 5I S TIN 0 - 255 0
D041 5P S CON 0 - 255 0
D042 5P S BRI 0 - 255 0
D043 5P S SHA 0 - 255 0
D044 5P S COL 0 - 255 0
D045 5P S TIN 0 - 255 0
D046 HD75 S CON 0 - 255 0
D047 HD75 S BRI 0 - 255 0
Item No. Item name Variable range Setting value
D048 HD75 S SHA 0 - 255 0
D049 HD75 S COL 0 - 255 0
D050 HD75 S TIN 0 - 255 0
D051 HD25 S CON 0 - 255 0
D052 HD25 S BRI 0 - 255 0
D053 HD25 S SHA 0 - 255 0
D054 HD25 S COL 0 - 255 0
D055 HD25 S TIN 0 - 255 0
D056 HDMI5I S CON 0 - 255 0
D057 HDMI5I S BRI 0 - 255 0
D058 HDMI5I S SHA 0 - 255 0
D059 HDMI5I S COL 0 - 255 0
D060 HDMI5I S TIN 0 - 255 0
D061 HDMI5P S CON 0 - 255 0
D062 HDMI5P S BRI 0 - 255 0
D063 HDMI5P S SHA 0 - 255 0
D064 HDMI5P S COL 0 - 255 0
D065 HDMI5P S TIN 0 - 255 0
D066 HDMI75 S CON 0 - 255 0
D067 HDMI75 S BRI 0 - 255 0
D068 HDMI75 S SHA 0 - 255 0
D069 HDMI75 S COL 0 - 255 0
D070 HDMI75 S TIN 0 - 255 0
D071 HDMI25 S CON 0 - 255 0
D072 HDMI25 S BRI 0 - 255 0
D073 HDMI25 S SHA 0 - 255 0
D074 HDMI25 S COL 0 - 255 0
D075 HDMI25 S TIN 0 - 255 0
D076 HDMIPC S CON 0 - 255 0
D077 HDMIPC S BRI 0 - 255 0
D078 HDMIPC S SHA 0 - 255 0
D079 HDMIPC S COL 0 - 255 0
D080 HDMIPC S TIN 0 - 255 0
D081 STD BRI1 0 - 255 0
D082 STD CON 0 - 255 8
D083 STD BRI2 0 - 255 247
D084 STD SHA 0 - 255 20
D085 STD COL 0 - 255 245
D086 STD TIN 0 - 255 0
D087 SFT BRI1 0 - 255 245
D088 SFT CON 0 - 255 8
D089 SFT BRI2 0 - 255 249
D090 SFT SHA 0 - 255 20
D091 SFT COL 0 - 255 245
D092 SFT TIN 0 - 255 0
D093 BRI BRI1 0 - 255 10
D094 BRI CON 0 - 255 18
D095 BRI BRI2 0 - 255 249
D096 BRI SHA 0 - 255 25
D097 BRI COL 0 - 255 250
Item No. Item name Variable range Setting value
