JVC LT-32A70BU Service Manual

1-18 (No.YA492)
4.6 INITIAL SETTING VALUES IN THE SERVICE MODE
• Perform fine-tuning based on the "initial values" using the remote control when in the Service mode.
• The "initial values" serve only as an indication rough standard and therefore the values with which optimal display can be achieved
may be different from the default values. But, don't change the values that are not written in "ADJUSTMENT PROCEDURE". They
are fixed values.
4.6.1 ADJUSTMENT MODE
4.6.1.1 VIDEO SYSTEM SETTING-1
Item No. Item name Variable range Setting value
S001 CVBS R OF 0 - 255 130
S002 CVBS G OF 0 - 255 130
S003 CVBS B OF 0 - 255 129
S004 5I R OF 0 - 255 0
S005 5I G OF 0 - 255 0
S006 5I B OF 0 - 255 0
S007 5P R OF 0 - 255 0
S008 5P G OF 0 - 255 0
S009 5P B OF 0 - 255 0
S010 HD75 R OF 0 - 255 0
S011 HD75 G OF 0 - 255 0
S012 HD75 B OF 0 - 255 0
S013 HD25 R OF 0 - 255 0
S014 HD25 G OF 0 - 255 0
S015 HD25 B OF 0 - 255 0
S016 HDMI5I R OF 0 - 255 0
S017 HDMI5I G OF 0 - 255 0
S018 HDMI5I B OF 0 - 255 0
S019 HDMI5P R OF 0 - 255 0
S020 HDMI5P G OF 0 - 255 0
S021 HDMI5P B OF 0 - 255 0
S022 HDMI75 R OF 0 - 255 0
S023 HDMI75 G OF 0 - 255 0
S024 HDMI75 B OF 0 - 255 0
S025 HDMI25 R OF 0 - 255 0
S026 HDMI25 G OF 0 - 255 0
S027 HDMI25 B OF 0 - 255 0
S028 HDMIPC R OF 0 - 255 0
S029 HDMIPC G OF 0 - 255 2
S030 HDMIPC B OF 0 - 255 0
S031 CVBS R DR 0 - 255 131
S032 CVBS G DR 0 - 255 146
S033 CVBS B DR 0 - 255 127
S034 5I R DR 0 - 255 0
S035 5I G DR 0 - 255 0
S036 5I B DR 0 - 255 0
S037 5P R DR 0 - 255 0
S038 5P G DR 0 - 255 0
S039 5P B DR 0 - 255 0
S040 HD75 R DR 0 - 255 0
S041 HD75 G DR 0 - 255 0
S042 HD75 B DR 0 - 255 0
S043 HD25 R DR 0 - 255 0
S044 HD25 G DR 0 - 255 0
S045 HD25 B DR 0 - 255 0
S046 HDMI5I R DR 0 - 255 0
S047 HDMI5I G DR 0 - 255 0
S048 HDMI5I B DR 0 - 255 0
S049 HDMI5P R DR 0 - 255 0
S050 HDMI5P G DR 0 - 255 0
S051 HDMI5P B DR 0 - 255 0
S052 HDMI75 R DR 0 - 255 0
S053 HDMI75 G DR 0 - 255 0
S054 HDMI75 B DR 0 - 255 0
S055 HDMI25 R DR 0 - 255 0
S056 HDMI25 G DR 0 - 255 0
S057 HDMI25 B DR 0 - 255 0
S058 HDMIPC R DR 0 - 255 0
S059 HDMIPC G DR 0 - 255 0
S060 HDMIPC B DR 0 - 255 0
S061 CVBS CL R OF 0 - 255 0
S062 CVBS CL G OF 0 - 255 0
S063 CVBS CL B OF 0 - 255 0
S064 CVBS WM R OF 0 - 255 0
S065 CVBS WM G OF 0 - 255 0
S066 CVBS WM B OF 0 - 255 0
S067 HD CL R OF 0 - 255 0
S068 HD CL G OF 0 - 255 0
S069 HD CL B OF 0 - 255 0
S070 HD WM R OF 0 - 255 0
S071 HD WM G OF 0 - 255 0
S072 HD WM B OF 0 - 255 0
S073 HDMI CL R OF 0 - 255 0
S074 HDMI CL G OF 0 - 255 0
S075 HDMI CL B OF 0 - 255 0
S076 HDMI WM R OF 0 - 255 0
S077 HDMI WM G OF 0 - 255 0
S078 HDMI WM B OF 0 - 255 0
S079 CVBS CL R DR 0 - 255 255
S080 CVBS CL G DR 0 - 255 0
S081 CVBS CL B DR 0 - 255 3
S082 CVBS WM R DR 0 - 255 8
S083 CVBS WM G DR 0 - 255 0
S084 CVBS WM B DR 0 - 255 242
S085 HD CL R DR 0 - 255 255
S086 HD CL G DR 0 - 255 0
S087 HD CL B DR 0 - 255 3
