PREPARATION
Set up and connections
Check accessories
Care when setting
■ Power requirements
• Connect the power cord only to a 110-240V, 50/60Hz AC outlet.
(Except China, Russia : connect to a 220-240V, 50/60Hz AC outlet.)
■ When attaching the TV to the wall, use the optional JVC wall
mounting unit.
• Consult a qualifi ed technician.
• JVC assumes no responsibility for damage due to improper mounting.
• 200mm x 200mm mount which conforms to VESA standards.
■ Installation requirements
• To avoid overheating, ensure the unit has ample room.
• After all the connections have been made, insert the plug into an AC
outlet.
• If both composite and S-VIDEO cables are connected, S-VIDEO will
be enable.
Please read the user manuals of each device carefully before setup.
It is necessary to connect an aerial to watch TV.
■ Connect with other devices “Connecting external devices” (P.4)
Connect an aerial and VCR / DVD Player
■ Insert the batteries
Use two “AA/R06” dry cell batteries.
Insert the batteries item the · and,
making sure the ª and · position
are correct.
Remote control
(RM-C1920)
“AA/R06” Batteries
For confi rming
the TV works
VCR (DVD Player)
OR
AERIAL
