4.6 INITIAL SETTING VALUE OF SERVICE MODE
• Perform fine-tuning based on the "initial values" using the remote control when in the Service mode.
• The "initial values" serve only as an indication rough standard and therefore the values with which optimal display can be achieved
may be different from the default values.
• Never change the values of the items( ) that are not described in ADJUSTMENT PROCEDURE or in the below table as they
are fixed values.
4.6.1 TV-MICRO SERVICE MODE SETTING VALUE
4.6.1.1 VIDEO SYSTEM SETTING
4.6.1.2 NOT USED ITEM
Item No. Item Variable range Setting value
S001 R DRIVE 000 - 255 137
S002 G DRIVE 000 - 255 137
S003 B DRIVE 000 - 255 137
S004 RESERV 000 - 255 ---
S005 RESERV 000 - 255 ---
S006 RESERV 000 - 255 ---
S007 RESERV 000 - 255 ---
S008 RESERV 000 - 255 ---
S009 RESERV 000 - 255 ---
Item No. Item Variable range Setting value
T001 INPLEVEL 000 - 015 ---
T002 LOWSEPA 000 - 063 ---
T003 HIGHSEPA 000 - 063 ---
M001 1E00 00 - FF ---
M002 1E01 00 - FF ---
M003 1E02 00 - FF ---
M004 1E03 00 - FF ---
M005 1E04 00 - FF ---
M006 1E05 00 - FF ---
M007 1E06 00 - FF ---
M008 1E07 00 - FF ---
M009 1E08 00 - FF ---
M010 1E09 00 - FF ---
M011 1E0A 00 - FF ---
M012 1E0B 00 - FF ---
M013 1E0C 00 - FF ---
M014 1E0D 00 - FF ---
M015 1E0E 00 - FF ---
M016 1E0F 00 - FF ---
M017 1E10 00 - FF ---
M018 1E11 00 - FF ---
M019 1E12 00 - FF ---
M020 1E13 00 - FF ---
M021 1E14 00 - FF ---
M022 1E15 00 - FF ---
M023 1E16 00 - FF ---
M024 1E17 00 - FF ---
M025 1E18 00 - FF ---
M026 1E19 00 - FF ---
M027 1E1A 00 - FF ---
M028 1E1B 00 - FF ---
M029 1E1C 00 - FF ---
M030 1E1D 00 - FF ---
M031 1E1E 00 - FF ---
M032 1E1F 00 - FF ---
M033 1E20 00 - FF ---
M034 1E21 00 - FF ---
M035 1E22 00 - FF ---
M036 1E23 00 - FF ---
M037 1E24 00 - FF ---
M038 1E25 00 - FF ---
M039 1E26 00 - FF ---
M040 1E27 00 - FF ---
M041 1E28 00 - FF ---
M042 1E29 00 - FF ---
M043 1E2A 00 - FF ---
M044 1E2B 00 - FF ---
M045 1E2C 00 - FF ---
M046 1E2D 00 - FF ---
M047 1E2E 00 - FF ---
M048 1E2F 00 - FF ---
M049 1E30 00 - FF ---
M050 1E31 00 - FF ---
M051 1E32 00 - FF ---
M052 1E33 00 - FF ---
M053 1E34 00 - FF ---
M054 1E35 00 - FF ---
M055 1E36 00 - FF ---
M056 1E37 00 - FF ---
M057 1E38 00 - FF ---
M058 1E39 00 - FF ---
M059 1E3A 00 - FF ---
M060 1E3B 00 - FF ---
M061 1E3C 00 - FF ---
M062 1E3D 00 - FF ---
M063 1E3E 00 - FF ---
M064 1E3F 00 - FF ---
M065 1E40 00 - FF ---
Item No. Item Variable range Setting value

JVC LT-37X688 Specifications

General

Integrated clock	Yes
Comb filter	Digital
Display diagonal	37 \
Display brightness	500 cd/m²
Native aspect ratio	16:9
Viewing angle, horizontal	176 °
Analog signal format system	NTSC
HDCP	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video outputs quantity	1
Product color	Black
RMS rated power	20 W

Weight and Dimensions

Depth (without stand)	232 mm
Width (without stand)	927.1 mm
Height (without stand)	654.05 mm
Weight (without stand)	18280 g
