JVC LT-52X579 User Manual

1-2 (No.YA654<Rev.001>)
SPECIFICATION
Design & specifications are subject to change without notice.
Items Contents
Dimensions ( W × H × D ) 125.8 cm × 87.57 cm × 34.57 cm (49-1/2" × 34-1/2" × 13-5/8") [with stand]
125.8 cm × 82.5 cm × 12.29 cm (49-1/2" × 32-1/2" × 4-13/16") [without stand]
Mass 34.0 kg (74.8 lbs) [with stand]
29.7 kg (65.3 lbs) [without stand]
Power Input AC120 V , 60 Hz
Power Consumption 276W (Max)
TV RF System
(Analog / Digital)
Analog
Digital
CCIR (M)
ATSC terrestrial / Digital cable
Color System (Analog) NTSC
Stereo System (Analog) BTSC (Multi Channel Sound)
Teletext System (Analog) Closed caption (T1-T4 / CC1-CC4)
TV Receiving Channels
and Frequency (Analog)
VHF Low
VHF High
UHF
CATV
02 ch - 06 ch : 54 MHz - 88 MHz
07 ch - 13 ch : 174 MHz - 216 MHz
14 ch - 69 ch : 470 MHz - 806 MHz
54 MHz - 804 MHz
Low Band : 02 - 06
High Band : 07 - 13
Mid Band : 14 - 22
Super Band : 23 - 36
Hyper Band : 37 - 64
Ultra Band : 65 - 94, 100 - 135
Sub Mid Band : 01, 96 - 99
TV / CATV Total Channel 191 Channels
Intermediate Frequency
(Analog)
Video IF
Sound IF
45.75 MHz
41.25 MHz (4.5 MHz)
Color Sub Carrier Frequency (Analog) 3.58 MHz
LCD Panel 52V-inch wide aspect (16:9)
Screen Size Diagonal: 132.17 cm (H: 115.2 cm × V: 64.8 cm)
Display Pixels Horizontal : 1920 dots × Vertical : 1080 dots
Audio Power Output 10 W + 10 W
Speaker 4.0 cm × 16.0 cm, oval type(Oblique corn) × 2
Antenna Terminal
(VHF/UHF, ATSC / DIGITAL CABLE IN)
F-type connector, 75Ω unbalanced, coaxial × 1
Digital Input
[INPUT-1/2/3]
Digital(Video/Audio) HDMI 2-row 19pin connector × 3
(Digital-input terminal is not compatible with picture signals of personal computer)
Video: Supported format: 1080p / 1080i / 720p / 480p / 480i
Audio: 2ch L-PCM, 32 / 44.1 / 48 KHz, 16 / 20 / 24 bit
Analog (Audio) 500mV(rms) (-4dBs), high impedance, RCA pin jack × 2
Video / Audio Input
[INPUT-4]
Component Video
1080i / 720p
480p / 480i
RCA pin jack × 3
Y : 1 V (p-p) (Sync signal: 0.35V(p-p), 3-value sync.), 75 Ω
Pb/Pr : ±0.35V(p-p), 75 Ω
Y : 1 V (p-p), Positive (Negative sync.), 75 Ω
Cb/Cr : 0.7V(p-p), 75 Ω
S-Video Mini-DIN 4 pin × 1
Y: 1 V (p-p), Positive (Negative sync.), 75 Ω
C: 0.286V (p-p) (Burst signal), 75 Ω
Video 1 V (p-p), Positive (Negative sync.), 75 Ω, RCA pin jack × 1
Audio 500 mV (rms), High impedance, RCA pin jack × 2
Video / Audio Input
[INPUT-5]
Component Video
1080i / 720p
480p / 480i
RCA pin jack × 3
Y : 1 V (p-p) (Sync signal: 0.35V(p-p), 3-value sync.), 75 Ω
Pb/Pr : ±0.35V(p-p), 75 Ω
Y : 1 V (p-p), Positive (Negative sync.), 75 Ω
Cb/Cr : 0.7V(p-p), 75 Ω
Video 1 V (p-p), Positive (Negative sync.), 75 Ω, RCA pin jack × 1
Audio 500 mV (rms), High impedance, RCA pin jack × 2
Audio output (Fix) 500 mV (rms), Low impedance, RCA pin jack × 2
Digital Audio Optical Output Digital SPDIF × 1
Photo Viewer / Service USB connector × 1
Remote Control Unit RM-C2050 (AA/R6 battery × 2)
