4
ENGLISH
; RND (random) button
a AUX (auxiliary) input jack
s KD-G396/KD-G395: Disc information indicators—
TAG (Tag information), (track/file), (folder)
d DISC indicator
f Playback mode / item indicators—RND (random),
(disc), KD-G396/KD-G395: (folder),
RPT (repeat)
g Tuner reception indicators—MO (monaural),
ST (stereo)
h LOUD (loudness) indicator
j EQ (equalizer) indicator
k Tr (track) indicator
l Source display / Track number / Folder number /
Volume level indicator / Time countdown indicator
/ Main display
z Sound mode (iEQ: intelligent equalizer)
indicators—JAZZ, ROCK, HIP HOP, CLASSIC, POPS,
USER
Parts identification
Display window
Control panel — KD-G396/KD-G395/KD-G245
1 5 (up) / ∞ (down) buttons
2 0 (eject) button
3 (standby/on attenuator) button
4 KD-G396/KD-G395: Remote sensor
DO NOT expose the remote sensor to strong light
(direct sunlight or artificial lighting).
5 Loading slot
6 Display window
7 EQ (equalizer) button
8 DISP (display) button
9 (control panel release) button
p SRC (source) button
q 4 / ¢ buttons
w Control dial
e BAND button
r SEL (select) button
t M MODE button
y MO (monaural) button
u SSM (Strong-station Sequential Memory) button
i Number buttons
o RPT (repeat) button
EN02-07_KD-G396[U_UH]f.indd 4EN02-07_KD-G396[U_UH]f.indd 4 8/21/07 4:28:33 PM8/21/07 4:28:33 PM
