3-11
Input board
Block No. [0][2]
R1045 QRE141J-153Y C RESISTOR 15k
Ω
1/4W J
R1050 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R1051 QRE141J-104Y C RESISTOR 100k
Ω
1/4W J
R1052 QRE141J-104Y C RESISTOR 100k
Ω
1/4W J
R1053 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R1054 QRE141J-104Y C RESISTOR 100k
Ω
1/4W J
R1055 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R1070 QRE141J-222Y C RESISTOR 2.2k
Ω
1/4W J
R1080 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R1081 QRE141J-563Y C RESISTOR 56k
Ω
1/4W J
R1082 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R1083 QRE141J-563Y C RESISTOR 56k
Ω
1/4W J
R1084 QRE141J-563Y C RESISTOR 56k
Ω
1/4W J
R1085 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R1090 QRE141J-104Y C RESISTOR 100k
Ω
1/4W J
R1091 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R1092 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R1093 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R1094 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R1095 QRJ146J-470X UNF C RESISTOR 47
Ω
1/4W J
R1096 QRJ146J-470X UNF C RESISTOR 47
Ω
1/4W J
R1097 QRE141J-222Y C RESISTOR 2.2k
Ω
1/4W J
R1100 QRE141J-682Y C RESISTOR 6.8k
Ω
1/4W J
R1101 QRE141J-682Y C RESISTOR 6.8k
Ω
1/4W J
R1102 QRE141J-682Y C RESISTOR 6.8k
Ω
1/4W J
R1103 QRE141J-682Y C RESISTOR 6.8k
Ω
1/4W J
R1104 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
R1120 QRZ0224-R22 EMIT RESISTOR 0.22
Ω
R1121 QRE141J-563Y C RESISTOR 56k
Ω
1/4W J
R1122 QRE141J-202Y C RESISTOR 2k
Ω
1/4W J
R1123 QRE141J-202Y C RESISTOR 2k
Ω
1/4W J
R1124 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R1125 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
R1126 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
R1127 QRE141J-562Y C RESISTOR 5.6k
Ω
1/4W J
R1128 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R1129 QRE141J-104Y C RESISTOR 100k
Ω
1/4W J
R1140 QRZ0224-R22 EMIT RESISTOR 0.22
Ω
R1141 QRE141J-563Y C RESISTOR 56k
Ω
1/4W J
R1142 QRE141J-202Y C RESISTOR 2k
Ω
1/4W J
R1143 QRE141J-202Y C RESISTOR 2k
Ω
1/4W J
R1144 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R1145 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
R1146 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
R1147 QRE141J-562Y C RESISTOR 5.6k
Ω
1/4W J
R1148 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R1149 QRE141J-104Y C RESISTOR 100k
Ω
1/4W J
R1160 QRE141J-333Y C RESISTOR 33k
Ω
1/4W J
R1161 QRJ146J-122X UNF C RESISTOR 1.2k
Ω
1/4W J
R1162 QRJ146J-122X UNF C RESISTOR 1.2k
Ω
1/4W J
R1163 QRJ146J-122X UNF C RESISTOR 1.2k
Ω
1/4W J
R1180 QRZ0224-R22 EMIT RESISTOR 0.22
Ω
R1181 QRE141J-563Y C RESISTOR 56k
Ω
1/4W J
R1182 QRE141J-202Y C RESISTOR 2k
Ω
1/4W J
R1183 QRE141J-202Y C RESISTOR 2k
Ω
1/4W J
R1184 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R1185 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
R1186 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
R1187 QRE141J-562Y C RESISTOR 5.6k
Ω
1/4W J
R1188 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R1189 QRE141J-104Y C RESISTOR 100k
Ω
1/4W J
R1221 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R1222 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R1223 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R1224 QRE141J-681Y C RESISTOR 680
Ω
1/4W J
R1225 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R1226 QRE141J-272Y C RESISTOR 2.7k
Ω
1/4W J
R1227 QRE141J-681Y C RESISTOR 680
Ω
1/4W J
R1295 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R2010 QRJ146J-4R7X UNF C RESISTOR 4.7
Ω
1/4W J
R2011 QRE141J-333Y C RESISTOR 33k
Ω
1/4W J
R2012 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R2016 QRE141J-333Y C RESISTOR 33k
Ω
1/4W J
R2017 QRJ146J-470X UNF C RESISTOR 47
Ω
1/4W J
R2018 QRJ146J-470X UNF C RESISTOR 47
Ω
1/4W J
L1120 QQLZ035-R39 COIL 0.39uH
L1140 QQLZ035-R39 COIL 0.39uH
Symbol No.
Part No. Part Name Description Local
L1180 QQLZ035-R39 COIL 0.39uH
CN103 QGD2504C1-03Z CONNECTOR (1-3)
CN110 QGB2510J1-12 CONNECTOR B-B (1-12)
CN119 QGA3901F1-08 CONNECTOR W-B (1-8)
CN120 QGB2510J1-07 CONNECTOR B-B (1-7)
CN130 QGB2510J1-08 CONNECTOR B-B (1-8)
CN140 QGD2504C1-03Z CONNECTOR (1-3)
CN150 QGB2510K1-08 CONNECTOR B-B (1-8)
CN160 QGB2510K1-12 CONNECTOR B-B (1-12)
CN250 QGA7901F2-02 CONNECTOR W-B (1-2)
EP119 QNZ0136-001Z EARTH PLATE
EP120 E409182-001SM GRAND TERMINAL
EP121 GV40327-002A IC BRD.HOLDER EP 651
FT111 QNG0003-001Z FUSE CLIP
FT112 QNG0003-001Z FUSE CLIP
FT131 QNG0003-001Z FUSE CLIP
FT132 QNG0003-001Z FUSE CLIP
FT151 QNG0003-001Z FUSE CLIP
FT152 QNG0003-001Z FUSE CLIP
FT511 QNG0003-001Z FUSE CLIP
FT512 QNG0003-001Z FUSE CLIP
FT521 QNG0003-001Z FUSE CLIP
FT522 QNG0003-001Z FUSE CLIP
FT531 QNG0003-001Z FUSE CLIP
FT532 QNG0003-001Z FUSE CLIP
FW100 QJK015-083324-E WIRE
FW150 QUM154-16DGZ4-E FLAT WIRE
FW160 QUM156-14DGZ4-E FLAT WIRE
FW170 QUM154-14DGZ4-E FLAT WIRE
J100 QNB0298-001 SPK.TERMINAL
RY110 QSK0127-001 RELAY
RY120 QSK0127-001 RELAY
S500 QSW0812-001 VOLTAGE SWITCH
Symbol No.
Part No. Part Name Description Local
IC300
SN74AHCT08NS-X
IC
IC305 LB1641 IC
IC325 KIA278R05PI IC
IC350 UPD78F0547GC IC
IC400 KIA4558F-X IC
IC410 KIA4558F-X IC DK51EE,DK51UX
IC410 NJM4565E-X IC
DK51US,DK51UG,
DK51UN
IC430 KIA4558F-X IC
IC450 KIA4558F-X IC
IC470 R2S15904SP-X IC
IC473 KTC812T-X IC
IC490 R2S15904SP-X IC
IC500 KTC812T-X IC
IC510 R2S15904SP-X IC
IC560 KIA4558F-X IC
DK51EE,DK51A
DK51UX
IC560 NJM4565E-X IC
DK51US,DK51UG,
DK51UN
IC580 KIA4558F-X IC
DK51EE,DK51A,
DK51UX
IC580 NJM4565E-X IC
DK51US,DK51UG,
DK51UN
IC600 KTC812T-X IC
IC610 KTC812T-X IC
IC620 KTC812T-X IC
IC640 KIA4558F-X IC
IC650 KIA4558F-X IC
IC700 BH7868FS-X IC
Q3100 KRA102S-X DIGI TRANSISTOR
Q3101 KRC102S-X DIGI TRANSISTOR
Q3300 KTC3203/OY/-T TRANSISTOR
Q4000 KTC2875-X CHIP TR.
Q4001 KRA104S-X DIGI TRANSISTOR
Symbol No.
Part No. Part Name Description Local
