3-14
Front board
Block No. [0][3]
R4730 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4731 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R4732 NRSA63J-104X MG RESISTOR
100k
Ω
1/16W J
R4733 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R4800 NRSA63J-682X MG RESISTOR
6.8k
Ω
1/16W J
R4831 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R4832 NRSA63J-104X MG RESISTOR
100k
Ω
1/16W J
R4833 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R4901 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4902 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R4903 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R4920 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4921 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5001 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5002 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5003 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5101 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5102 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5103 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5104 QRE141J-223Y C RESISTOR 22k
Ω
1/4W J
R5120 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5121 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5201 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R5204 QRE141J-223Y C RESISTOR 22k
Ω
1/4W J
R5300 QRE141J-562Y C RESISTOR 5.6k
Ω
1/4W J
R5301 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R5302 QRE141J-823Y C RESISTOR 82k
Ω
1/4W J
R5400 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
R5401 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R5402 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R5404 QRE141J-153Y C RESISTOR 15k
Ω
1/4W J
R5500 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
R5501 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R5502 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R5504 QRE141J-153Y C RESISTOR 15k
Ω
1/4W J
R5600 QRE141J-152Y C RESISTOR 1.5k
Ω
1/4W J
R5601 NRSA63J-124X MG RESISTOR 120k
Ω
1/16W J
R5602 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R5603 QRE141J-153Y C RESISTOR 15k
Ω
1/4W J
R5700 QRE141J-152Y C RESISTOR 1.5k
Ω
1/4W J
R5701 NRSA63J-124X MG RESISTOR 120k
Ω
1/16W J
R5702 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R5703 QRE141J-153Y C RESISTOR 15k
Ω
1/4W J
R5800 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R5802 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R5803 QRE141J-223Y C RESISTOR 22k
Ω
1/4W J
R5804 QRE141J-223Y C RESISTOR 22k
Ω
1/4W J
R5820 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R6000 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6001 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6002 QRE141J-182Y C RESISTOR 1.8k
Ω
1/4W J
R6003 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R6101 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6102 QRE141J-182Y C RESISTOR 1.8k
Ω
1/4W J
R6103 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R6111 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6112 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R6113 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R6200 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6201 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6202 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R6203 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R6301 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6302 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R6303 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R6311 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6312 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R6313 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R6400 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6401 QRE141J-223Y C RESISTOR 22k
Ω
1/4W J
R6402 QRE141J-223Y C RESISTOR 22k
Ω
1/4W J
R6403 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R6404 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R6420 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R6500 QRE141J-513Y C RESISTOR 51k
Ω
1/4W J
R6501 QRE141J-223Y C RESISTOR 22k
Ω
1/4W J
R6502 NRSA63J-393X MG RESISTOR 39k
Ω
1/16W J
R6503 NRSA63J-513X MG RESISTOR 51k
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
R6520 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R6600 QRE141J-513Y C RESISTOR 51k
Ω
1/4W J
R6601 QRE141J-223Y C RESISTOR 22k
Ω
1/4W J
R6602 NRSA63J-393X MG RESISTOR 39k
Ω
1/16W J
R6603 NRSA63J-513X MG RESISTOR 51k
Ω
1/16W J
R6700 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
DK51EE,DK51US,
DK51UX,DK51UG,
DK51UN
R6701 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
DK51EE,DK51US,
DK51UX,DK51UG,
DK51UN
R6800 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
DK51EE,DK51US,
DK51UX,DK51UG,
DK51UN
R6801 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
DK51EE,DK51US,
DK51UX,DK51UG,
DK51UN
R7000 NRSA63J-201X MG RESISTOR 200
Ω
1/16W J
R7002 NRSA63J-201X MG RESISTOR 200
Ω
1/16W J
R7004 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R7005 NRSA63J-201X MG RESISTOR 200
Ω
1/16W J
R7006 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R7007 NRSA63J-201X MG RESISTOR 200
Ω
1/16W J
R7008 NRSA63J-751X MG RESISTOR 750
Ω
1/16W J
R7009 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R7300 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R7301 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R7302 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R7500 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R7501 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R7502 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
CN300 QGF1036C2-05 CONNECTOR FFC/FPC (1-5)
CN301 QGF1036C2-25 CONNECTOR FFC/FPC (1-25)
CN302 QGF1036C2-15 CONNECTOR FFC/FPC (1-15)
CN303 QGF1205C2-19 CONNECTOR FFC/FPC (1-19)
CN304 QGF1205F2-05 CONNECTOR FFC/FPC (1-5)
CN306 QGF1205C2-09 CONNECTOR FFC/FPC (1-9)
CN307 QGF1205C2-19 CONNECTOR FFC/FPC (1-19)
CN308 QGF1205C2-07 CONNECTOR FFC/FPC (1-7)
CN309 QGB2510K1-08 CONNECTOR B-B (1-8)
CN310 QGB2510J1-10 CONNECTOR B-B (1-10)
CN311 QGB2510K1-07 CONNECTOR B-B (1-7)
CN312 QGD2504C1-03Z CONNECTOR (1-3)
CN313 QGD2504C1-03Z CONNECTOR (1-3)
CN314 QGD2504C1-04Z CONNECTOR (1-4)
CN330 QGA2501C1-03 CONNECTOR W-B (1-3)
CN335 QGF1205C2-11 CONNECTOR FFC/FPC (1-11)
HS325 LV40057-002A HEAT SINK
J6700 QNN0420-001 SURROUND JACK
DK51EE,DK51US,
DK51UX,DK51UG,
DK51UN
J7300 QNN0779-001 VIDEO JACK
J7500 QNN0557-002 PIN JACK
K3100 QQR0621-001Z COIL
K4730 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K4731 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
SC325 QYSBSG3008ZA TAP SCREW M3 x 8mm
X3500 QAX0724-001Z CRYSTAL 12.000000MHz
Symbol No.
Part No. Part Name Description Local
IC901 PT6315 IC
IC902 GP1UM281XKVF IR DETECT UNIT
IC950 PT2399-S-W ECHO IC
DK51EE,DK51US,
DK51UX,DK51UG,
DK51UN
IC960 KIA4558F-X IC
DK51EE,DK51US,
DK51UX,DK51UG,
DK51UN
IC970 KIA4558F-X IC DK51A
Symbol No.
Part No. Part Name Description Local
