General assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 GV10057-010A FRONT PANEL
2 E75896-001 FELT SPACER (x2)
3 GV40077-002A JVC BADGE
4 GV40136-001A STBY.INDICATOR
5 GV30154-005A CD BUTTON
6 GV20104-002A CD EJECT BUTTON
7 GV30137-001A POWER BUTTON
8 GV30177-009A CONTROL BTTN.AS
9 GV30139-001A REMOTE LENS
10 QYSDSF2608Z SCREW 2.6mm x 8mm(x12)
11 QYSDSF2608Z SCREW 2.6mm x 8mm(x3)
12 QYSDSF2608Z SCREW 2.6mm x 8mm(x7)
13 QYSDSF2608Z SCREW 2.6mm x 8mm(x4)
14 GV30129-001A STAY BRACKET
15 GV10060-016A ORNAMENT
16 QYSDSF2608Z SCREW 2.6mm x 8mm(x4)
17 E310243-002 PLASTIC RIVET
18 GV20103-004A SUB. PANEL
19 GV30138-001A FRONT BUTTON
20 GV40185-002A COVER SHEET
21 GV30211-008A C.HOLD.ASSY.(L)
22 GV30212-008A C.HOLD.ASSY.(R)
23 GV20099-002A EJECT BUTTON(A)
24 GV20100-002A EJECT BUTTON(B)
25 FMKW4009-002 HOLDER SPRING A
26 FMKW4010-002 HOLDER SPRING B
27 FMKW4011-001 SPRING
28 FMKS3002-003 EJECT LEVER(A)
29 FMKS3003-003 EJECT LEVER(B)
30 GV40034-001A DAMPER ASSY. (x2)
31 VKY4180-401 CASSETTE SPRING (x4)
32 FMKL4012-004 EJECT SAFETY(A)
33 FMKL4013-001 EJECT SAFETY(B)
34 FMKW4007-001 SPRING (A)
35 FMKW4008-001 SPRING (B)
36 GV20094-001A HOLDER BRACKET
37 QYSBSG3010Z TAPPING SCREW 3mm x 10mm(x2)
38 QYSBSG3010Z TAPPING SCREW 3mm x 10mm(x2)
39 QYSBSG3010Z TAPPING SCREW 3mm x 10mm(x3)
40 QYSBSF3012Z TAP SCREW 3mm x 12mm(x4)
41 GV30124-001A TRANS SHIELD
42 E3400-431 SPACER
43 LV40761-003A INSULATOR (x2)
44 LV40761-003A INSULATOR (x2)
45 VKS3703-00Q CLAMPER ASSY
46 QYSPST2606Z TAP SCREW 2.6mm x 6mm
47 VKW5187-001 ROD
48 QUQ610-1609AJ FLAT WIRE
49 VDM1001-M002AV WIRE&TUBE
50 QYSBSF2608Z TAPPING SCREW 2.6mm x 8mm(x4)
51 VYSA1R2-033 SPACER
52 GV40189-001A FAN BRACKET
53 QYSBSF3010Z TAP SCREW 3mm x 10mm(x2)
54 QYSBSG3035Z TAP SCREW M3 x 35mm(x2)
55 E310243-002 PLASTIC RIVET (x2)
56 QYSBSF3008Z SCREW 3mm x 8mm
57 GV30223-001A BRACKET
58 E310243-002 PLASTIC RIVET
59 GV10061-001A CHASSIS BASE
60 E75896-006 FELT SPACER (x2)
61 GV30191-002A HEAT SINK
62 QYSBSG3014E TAP SCREW 3mm x 14mm(x4)
63 GV40143-001A LEAF SPRING
64 QYSBSG3014E TAP SCREW 3mm x 14mm(x2)
65 QYSDSTL4008Z ASSY SCREW 4mm x 8mm(x4)
66 QYSBSGG3008E TAPPING SCREW 3mm x 8mm(x2)
67 QYSBSGG3008E TAPPING SCREW 3mm x 8mm
 68 QZW0033-001 STRAIN RELIEF
69 GV40236-001A PLASTIC HOLDER
70 GV10062-067A REAR PANEL
71 GV10063-002A REAR COVER
72 QYSBSG3010Z TAPPING SCREW 3mm x 10mm(x2)
73 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
74 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x4)
75 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
76 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
77 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
78 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
79 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
80 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
81 QYSBSF3012E SPECIAL SCREW 3mm x 12mm(x2)
82 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
83 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
84 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
85 GV10055-001A/S/ METAL COVER
86 QYSDSG3006M TAP SCREW 3mm x 6mm(x2)
87 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x6)
88 GV20106-008A CD FITTING (1)
89 GV20107-008A CD FITTING (2)
90 GV20108-008A CD FITTING (3)
91 GV30473-001A VOLUME KNOB
92 GV30472-001A SUBWOOFER KNOB
93 GV30471-001A SND.MODE KNOB
94 GV30470-001A CD FORWARD KNOB
95 GV20098-025A WINDOW SCREEN
96 GV40181-001A MIRROR SHEET
97 GV30155-001A VOLUME RING
98 GV30151-001A SUB.WOOFER RING
99 GV30152-001A SOUND MODE RING
100 GV30153-001A CD FORWARD RING
101 GV40083-002A MIC KNOB
102 GV40186-001A NUT
 103 QQT0322-003 POWER TRANSF T 001
 104 QMF51E2-4R0-J1 FUSE
F 001 4A
AC250V
 105 QMF51E2-2R0-J1 FUSE
F 003 2A
AC250V
 106 QMF51E2-4R0-J1 FUSE
F 101 4A
AC250V
 107 QMF51E2-4R0-J1 FUSE
F 102 4A
AC250V
108 QUQH10-1908BJ CARD WIRE
109 QUQ412-0911DJ CARD WIRE
110 QUQ412-1710CJ CARD WIRE
111 QUQ412-1710CJ CARD WIRE
112 QUQ412-1020CJ CARD WIRE
113 QUQ412-0915CJ CARD WIRE
114 QUQ412-2410CJ CARD WIRE
115 QUQH10-1506BJ FFC CABLE
116 QUQH10-1508BJ CARD WIRE
 117 QMPK210-205-JN POWER CORD(EU) 2.05m BLACK
MXGA
9VU,
MXGA
9VUN
 117 QMPR270-200-JD POWER CORD(EU) 2m BLACK
MXGA
9VUX
118 QAR0228-003 FAN
119 GV30141-001A FL HOLDER
120 E3400-439 SPACER (x2)
121 E406507-001 MECHA C. LABEL
 Symbol No. Part No. Part Name Description Local
