Main board
Block No. [0][2][0][0]
 R249 QRJ146J-1R0X UNF C RESISTOR 1 Ω 1/4W J
R281 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R283 QRE141J-153Y C RESISTOR 15k Ω 1/4W J
R284 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R384 QRE141J-272Y C RESISTOR 2.7k Ω 1/4W J
R385 QRE141J-562Y C RESISTOR 5.6k
Ω 1/4W J
R389 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
 R601 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
 R602 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
R603 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R604 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R605 QRJ146J-102X UNF C RESISTOR 1k Ω 1/4W J
 R606 QRJ146J-102X UNF C RESISTOR 1k Ω 1/4W J
R607 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R608 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R613 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R614 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R615 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R616 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R617 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R618 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R619 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R620 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R621 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R623 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
 R639 QRL01DJ-821X OMF RESISTOR 820 Ω 1W J
 R640 QRL01DJ-821X OMF RESISTOR 820 Ω 1W J
 R653 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
 R655 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
R666 QRE141J-333Y C RESISTOR 33k Ω 1/4W J
R667 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R668 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
 R674 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R675 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R676 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R680 QRE141J-105Y C RESISTOR 1M Ω 1/4W J
R681 QRE141J-392Y C RESISTOR 3.9k Ω 1/4W J
R682 QRE141J-475Y C RESISTOR 4.7M Ω 1/4W J
 R701 QRJ146J-470X UNF C RESISTOR 47 Ω 1/4W J
 R702 QRJ146J-470X UNF C RESISTOR 47 Ω 1/4W J
R703 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R704 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R705 QRJ146J-821X UNF C RESISTOR 820 Ω 1/4W J
 R706 QRJ146J-821X UNF C RESISTOR 820 Ω 1/4W J
R707 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R708 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R713 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R714 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R715 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R716 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R717 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R718 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R719 QRE141J-562Y C RESISTOR 5.6k
Ω 1/4W J
R720 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R721 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R722 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R723 QRE141J-682Y C RESISTOR 6.8k Ω 1/4W J
R724 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
R725 QRE141J-823Y C RESISTOR 82k Ω 1/4W J
R726 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R727 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R728 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R729 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R730 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R733 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R734 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R735 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R736 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
 R739 QRL01DJ-821X OMF RESISTOR 820 Ω 1W J
 R740 QRL01DJ-821X OMF RESISTOR 820 Ω 1W J
R741 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
R742 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
 R753 QRZ0197-R22 EMIT RESISTOR 0.22 Ω
 R754 QRZ0197-R22 EMIT RESISTOR 0.22 Ω
R761 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R762 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R766 QRE141J-333Y C RESISTOR 33k
Ω 1/4W J
R768 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
 Symbol No. Part No. Part Name Description Local
R769 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
 R774 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R775 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R776 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R777 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R778 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R786 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R787 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R790 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R792 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R793 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R794 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R795 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R796 QRE141J-682Y C RESISTOR 6.8k Ω 1/4W J
R797 QRE141J-203Y C RESISTOR 20k Ω 1/4W J
 R798 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R908 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
L601 QQLZ035-R39 COIL 0.39uH
L602 QQLZ035-R39 COIL 0.39uH
L701 QQLZ035-R39 COIL 0.39uH
L702 QQLZ035-R39 COIL 0.39uH
CN201 QGB2510J1-11 CONNECTOR B-B (1-11)
CN202 QGB2510J1-10 CONNECTOR B-B (1-10)
CN203 QGB2510J1-04 CONNECTOR B-B (1-4)
CN204 QGA3901C1-07 CONNECTOR W-B (1-7)
CN205 QGB2510J1-14 CONNECTOR B-B (1-14)
CN206 QGB2510J1-12 CONNECTOR B-B (1-12)
CN207 QGB2510J1-10 CONNECTOR B-B (1-10)
CN215 QGB2510K2-14 CONNECTOR B-B (1-14)
CN703 QGD2504C1-03Z CONNECTOR (1-3)
CN704 QGD2504C1-03Z CONNECTOR (1-3)
CN705 QGA2501C1-02 CONNECTOR W-B (1-2)
CN706 QGD2504C1-03Z CONNECTOR (1-3)
EP201 QNZ0136-001Z EARTH PLATE
EP202 QNZ0136-001Z EARTH PLATE
FW707 QUM153-09Z4Z4 FLAT WIRE
FW901 QUM027-13DGZ4 FLAT WIRE
JS901 QSW0911-001 ROTARY SW
S901 QSW0825-001Z TACT SW
S902 QSW0825-001Z TACT SW
 Symbol No. Part No. Part Name Description Local
IC436 TDA7439 IC Control volume
IC466 BA3837 IC MIC Mixer
IC481 NJM4580D IC
LPF Mic and
H.phone amp.
IC501 NJM4580D IC
LPF Mic and
H.phone amp.
IC502 NJM4580D IC
LPF Mic and
H.phone amp.
IC526 NJM4580D IC
LPF Mic and
H.phone amp.
IC571 NJM4580D IC
LPF Mic and
H.phone amp.
Q401 2SC3576-JVC-T TRANSISTOR
Q402 2SC3576-JVC-T TRANSISTOR
Q481 2SC3576-JVC-T TRANSISTOR
Q482 2SC3576-JVC-T TRANSISTOR
Q483 KRA102M-T DIGI TRANSISTOR
Q556 2SC3576-JVC-T TRANSISTOR
Q557 2SC3576-JVC-T TRANSISTOR
Q562 2SC3576-JVC-T TRANSISTOR
Q571 2SC2785/FE/-T TRANSISTOR
Q572 2SC2785/FE/-T TRANSISTOR
Q573 2SC2785/FE/-T TRANSISTOR
Q585 2SC2785/FE/-T TRANSISTOR
Q586 2SC2785/FE/-T TRANSISTOR
Q999 KRA102M-T DIGI TRANSISTOR
 Symbol No. Part No. Part Name Description Local
